5.2 LEFT COVER UNIT
B
12
13
14
15
11
16
17
3
2
18
19
D
117
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-920002-B SIDE LEFT COVER Part 1
2 551613-000001 M22-PV/K11(LABLE:60mm) EMERGENCY SWITCH Part 2
3 V080-L92009-B MAIN POWER CE PANEL Part 1
4 551611-000001 M22-DL-G(STATR, 1A+LED) LAMP SWITCH Part 1
5 551611-000002 M22-DL-R(STOP, 1A+LED) LAMP SITCH Part 1
6 552214-000001 TN32-2(WHT/GRN) INDICATOR LAMP Part 1
7 551612-000004 M22-WRS/KW40(Key S/W, 1a * 6EA, con. power) KEY SWITCH Part 1
8 551615-000001 TO-2-1/EA/SVB(MAIN SW) MAIN SWITCH Part 1
9 V085-910002-A DOOR SUPPORT Part 2
10 609022-000003 F6-1 HINGE Part 2
11 V085-920012-B MAGNET BRACKET 2 Part 3
12 V085-920029-A MAGNET BRACKET 3 Part 1
13 609027-000008 KC-312-2-1-A BALL CATCH Part 1
14 V080-920035-B INTERLOCK GUIDE Part 2
15 551614-000001 AZ17-11ZK-B1 INTERLOCK S/W Part 1
16 609027-000002 56x16x12 TOP MAGNET CATCH Part 1
17 V085-910006-A MAGNET BRACKET Part 2
18 552511-000002 DP201A2123HBT-120X120X38 FAN Part 1
19 552590-000001 RS1A01AA(50W) FAN FILTER Part 1
5.2 LEFT COVER UNIT
118
