4.4 F OURT H MOV I NF RAIL ( REAR) 20 16 17 18 19 21 22 23 24 25 81
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-510005-A KY8030DL RAIL 4 Part 1
2 V085-510008-A PCB GUIDE RAIL-2 Part 1
3 A010-520005 HEIGHT GUIDE Assembly 1 4.1.4
4 V085-510007-A PCB GUIDE RAIL-1 Part 1
5 A010-D52002 UP/DOWN RAIL Assembly 1 4.1.6
6 V080-500020 STOPPER 2 Assembly 1 4.4.1
7 A010-510026-B COLLISION SENSOR BKT Part 1
8 554011-000009 E3S-LS3NW PHOTO SENSOR Part 1
9 A010-520009 SENSOR Assembly 1 4.1.8
10 A010-520010 SENSOR Assembly 1 4.1.9
11 602415-000019 SMALL 3D FRANGE ROLLER ROLLER Part 11
12 602415-000016 ESD D FLANGE BELT ROLLER ROLLER Part 4
13 A010-520006-C LIMIT SENSOR DOG Part 1
14 A010-D52016-A SENSOR DOG 5 Part 1
15 A010-520016-A SMALL BELT GUIDE Part 2
4.4 FOURTH MOVINF RAIL (FRONT)
80
4.4 FOURTH MOVINF RAIL (REAR)
20
16
17
18
19
21
22
23
24
25
81
No. Item Code No. Specification Description Type Q’TY Remark
16 A010-D51021-A LM GUIDE BLOCK Part 2
17 A010-D52002 UP/DOWN RAIL Assembly 1 4.1.6
18 A010-620004 TENSIONER Assembly 1 4.1.5
19 A010-520002 LEFT LM FIX BKT Assembly 2 4.1.1
20 A010-520003 RIGHT LM FIX BKT Assembly 1 4.1.2
21 554011-000005 PM-Y44 PHOTO SENSOR Part 1
22 V085-520011-A LANE 2 CAFLUX BKT Part 1
23 A010-D52018-A CONNECTER BKT 3 Part 1
24 A010-D52017-A CONNECTER BKT 2 Part 1
25 V085-510009-A WORK GUIDE RAIL Part 1
4.4 FOURTH MOVINF RAIL (REAR)
82
