KY8030-2XDL(2P) Part List.pdf - 第9页
No. Item Code No. Specific ati on Description Type Q’TY Remark 1 V085-1 00000 MAIN FRAME Assembly 1 2 V085-1 20000 ELECTRIC BOX UNIT Assembly 1 3 V085-2 00000 X G ANTRY UNIT Assembly 1 4 V085-3 00000 Y GANTRY UNIT Ass em…
8
KY8030-2XDL Machine Composition
7
3
1
2
5
4
6
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-100000 MAIN FRAME Assembly 1
2 V085-120000 ELECTRIC BOX UNIT Assembly 1
3 V085-200000 X GANTRY UNIT Assembly 1
4 V085-300000 Y GANTRY UNIT Assembly 1
5 V085-500000 DUAL LANE CONVEYOR UNIT Assembly 1
6 P031-900-000 PROBE Assembly 1
7 V085-900000 WHOLE COVER UNIT Assembly 1
KY8030-2XDL Machine Composition
9
1. FRAME
10
1
2
6
4
5
7
8
9
3
