MODEL TCM-3100J-2
0108-001
190
㔚᳇ᓮㇱ ELECTRICAL SECTION
Fig.11-2 200V 㔚Ḯ Power Supply-200V
51
52
53
53
54
101
101
102
102
103
103
104
104
.
62-1
62-1
63
63
64
65
62
67
68
69
69
81
82
83
83
84
84
85
85
85-1
85-1
86
86
87
87
88
89
89
.
90
90
90
90
91
92
92
92
71
72
73
74
79
80
80
99
99
98
98
97
97
96
1
2
3
4
41
41
41
42
42
43
43
43
44
66
11
12
.
15-1
15-1
15
16
17
17
75
76
76
80
18
18
13
.
13-1
13-1
14
.
14-1
14
14
.
14-1
14-1
21
22
23
24
25
25
10
29
30
36
36
26
28
27
27
28
28
31
32
.
33
34
35
35
101
60
MODEL TCM-3100J-2
0108-001
191
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-2
1 630 056 1210 SUPPORT 1 659BC-03V-002
2 630 001 0220 WASHER 2 BW5
3 411 141 6705 WASHER SPR 5 2 SW5
4 630 000 7756 BOLT,HEX-SCT 2 M5X12
10 630 094 2910 PANEL 1 659BC-03V-001
11 630 053 8618 EM-CONTACTOR 2 MC8, MC9 659BC-03D-004
12 630 053 8601 EM-CONTACTOR 1 MC18 659BC-03D-062
13 630 049 0749 EM-CONTACTOR 1 MC11 659BC-03D-005
13 -1 630 049 2132 COVER 1 659BC-03D-051
14 630 049 0763 EM-CONTACTOR 3 MC10, MC6, MC7 659BC-03D-012
14 -1 630 049 2149 COVER 3 659BC-03D-050
15 630 049 0756 EM-CONTACTOR 1 MC4 659BC-03D-003
15 -1 630 049 2132 COVER 1 659BC-03D-051
16 411 119 2104 WASHER V 4X9X0.8 16 FW4 F
17 411 008 1706 WASHER SPR 4 16 SW4 F
18 411 042 3001 SCR PAN 4X10 16 M4X10 PAN
22 411 119 2104 WASHER V 4X9X0.8 3 FW4 F
23 411 008 1706 WASHER SPR 4 3 SW4 F
24 411 043 5004 SCR PAN 4X8 3 M4X8 PAN
25 630 088 9499 CIRCUIT PROTECTOR 2 CB208, CB209 659BC-03D-044
26 630 067 0349 CIRCUIT PROTECTOR 1 CB205 659BC-03D-045
27 630 067 3227 CIRCUIT PROTECTOR 1 CB211 659BC-03D-042
28 630 074 0196 CIRCUIT PROTECTOR 3 CB210, CB206, CB207
659BC-03D-043
29 630 068 8894 TERMINAL 1 659BC-03D-055
30 630 074 8369 WIRE PARTS 1 659BC-03D-054
31 630 049 3696 TERMINAL 6 659BC-03D-021
32 630 049 3757 ACCESSORY,WIRING 2 659BC-03D-025
33 630 049 3733 ACCESSORY,WIRING 1 659BC-03D-023
35 630 049 3672 BRACKET,WIRING 2 659BC-03D-026
36 630 049 3672 BRACKET,WIRING 1 659BC-03D-026
41 630 001 0220 WASHER 3 BW5
42 411 141 6705 WASHER SPR 5 3 SW5
43 630 000 7756 BOLT,HEX-SCT 3 M5X12
44 411 036 8609 SCR PAN+SW+W 5X12 1
51 630 056 1210 SUPPORT 1 659BC-03V-002
52 630 001 0220 WASHER 2 BW5
53 411 141 6705 WASHER SPR 5 2 SW5
54 630 000 7756 BOLT,HEX-SCT 2 M5X12
60 630 094 2927 PANEL 1 659BC-03V-003
62 630 000 3581 EM-CONTACTOR 1 MC14 659BC-03D-052
62 -1 630 049 2149 COVER 1 659BC-03D-050
63 411 119 2104 WASHER V 4X9X0.8 2 FW4 F
64 411 008 1706 WASHER SPR 4 2 SW4 F
65 411 042 3001 SCR PAN 4X10 2 M4X10 PAN
66 630 094 5591 FILTER,NOISE 1 NF3 659BC-03D-080
67 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
68 411 008 1706 WASHER SPR 4 4 SW4 F
69 411 042 3001 SCR PAN 4X10 4 M4X10 PAN
72 411 119 2104 WASHER V 4X9X0.8 2 FW4 F
MODEL TCM-3100J-2
0108-001
192
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-2
73 411 008 1706 WASHER SPR 4 2 SW4 F
74 411 043 5004 SCR PAN 4X8 2 M4X8 PAN
75 630 069 5915 CIRCUIT PROTECTOR 2 CB202, CB203 659BC-03D-041
76 630 091 1909 CIRCUIT PROTECTOR 1 CB201 659BC-03D-075
79 630 053 8601 EM-CONTACTOR 1 MC13 659BC-03D-027
80 630 049 3672 BRACKET,WIRING 3 659BC-03D-026
82 411 119 2104 WASHER V 4X9X0.8 3 FW4 F
83 411 008 1706 WASHER SPR 4 3 SW4 F
84 411 043 5004 SCR PAN 4X8 3 M4X8 PAN
85 630 049 2200 EM-CONTACTOR 2 MC2, MC3 659BC-03D-010
85 -1 630 100 1357 COMP,CR 6 659BC-03D-008
86 630 049 3696 TERMINAL 8 659BC-03D-021
87 630 049 3757 ACCESSORY,WIRING 3 659BC-03D-025
88 630 049 3733 ACCESSORY,WIRING 1 659BC-03D-023
90 630 049 3672 BRACKET,WIRING 2 659BC-03D-026
91 630 088 9482 CIRCUIT PROTECTOR 7 CB212-218 659BC-03D-061
92 630 049 3672 BRACKET,WIRING 2 659BC-03D-026
96 630 049 3696 TERMINAL 3 659BC-03D-021
97 630 049 3757 ACCESSORY,WIRING 1 659BC-03D-025
98 630 049 3733 ACCESSORY,WIRING 1 659BC-03D-023
99 630 049 3672 BRACKET,WIRING 1 659BC-03D-026
101 630 001 0220 WASHER 3 BW5
102 411 141 6705 WASHER SPR 5 3 SW5
103 630 000 7756 BOLT,HEX-SCT 3 M5X12
104 411 036 8609 SCR PAN+SW+W 5X12 1
