SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50282
15/17
Item Function
Notice Correct X
（mm）
Notice Correct Y
（mm）
Stop Correct X（mm）
Stop Correct Y（mm）
For each tape type, set Feeder MACS correction value to
make maintenance notice or stop.
Only 8mm feeder and 4mm feeder are acceptable.
By switching [Feeder Group] (“SS Type” or “ZS Type”）, it is
possible to set different values for SS feeder and ZS feeder.
A recommended value is set by default（Table 4.3）, so that
usually you don’t need to change the value.
The allowable range is 0.000 to 999.999 (mm).
When “0.000” is set, maintenance notice and stop is disabled
for the tape.
Notice Err Rate（%）
Stop Err Rate（%）
For each tape type, set pickup error rate to make maintenance
notice or stop.
By switching [Feeder Group] (“SS Type” or “ZS Type”）, it is
possible to set different values for SS feeder and ZS feeder.
A recommended value is set by default（Table 4.3）, so that
usually you don’t need to change the value.
The allowable range is 0.00 to 10.00 (%).
When “0.00” is set, maintenance notice and stop is disabled
for the tape.
Table 4.2 Notice timing
Notice timing Function
Power ON Displays the message when the first Return-to-Origin after
machine startup is completed.
* If feeders are on cart, the cart must be correctly set.
*When there is no correction value at the time of power on,
Feeder MACS correction value is excluded.
Feeder ON/OFF Displays the message when attaching or removing a feeder
that requires maintenance.
* Includes the following timing.
- The cart clamp switch is turned ON/OFF by hand.
- Cart clamp ON at machine startup.
- Cart clamp OFF at machine shutdown.
*When there is no correction value at the time of power on,
Feeder MACS correction value is excluded.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50282
16/17
Notice timing Function
Feeding count over Displays the message when feeding count exceeds the notice
count.
Once the message is displayed, it is not displayed again until
the board data is read or the feeder is removed. （but the
message is displayed on the other timing if selected as
well.）
Board change Displays the message at reading board data.
Reset Displays the message when the [RESET] button is pressed.
Power OFF Displays the message when the [OFF] button is pressed.
Time setting Displays the message at a given time, during auto-running or
not.
Table 4.3 Recommended notice count （Feeder maintenance period）
Notice Cnt (10,000times) Stop Cnt (10,000times)
Tape Type SS Feeder ZS Feeder SS Feeder ZS Feeder
4mm tape 5,000,000 5,000,000 7,500,000 7,500,000
8mm tape
12mm/16mm
tape
2,000,000 3,000,000
24mm tape
32mm tape 2,000,000 3,000,000
44mm tape
56mm tape
72mm tape
88mm tape
104mm tape
120mm tape
136mm tape
152mm tape
168mm tape
184mm tape
200mm tape
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50282
17/17
Table 4.4 Recommendation of Feeder MACS Correction value/Pickup Error Rate
（Recommended cycle of feeder maintenance）
Notice Correct
(mm)
Stop Correct (mm) Notice
Pickup Err
Rate (%)
Stop Pickup
Err Rate (%)
Tape Type X Y X Y
4mm tape 0.200 mm 0.200 mm 0.000 mm 0.000 mm 1.00 % 0.00 %
8mm tape
12mm/16mm tape Not
supported
Not
supported
Not
supported
Not
supported
24mm tape
32mm tape
44mm tape
56mm tape
72mm tape
88mm tape
104mm tape
120mm tape
136mm tape
152mm tape
168mm tape
184mm tape
200mm tape
- Recommended value is common between SS feeder and ZS feeder.
5. Limitation
This function has the following limitation.
1. When the special function “Feeder Maintenance Warning（Tok1183）” is used, this
function doesn’t work.
2. When you use maintenance notice based on pickup error rate, it is recommended to set
[Server Path]. If [Server Path] is not set, log is not taken over at power OFF/ON, and not
shared among other machines.
