Station Software 714.0 (R20-2) / Version Description 11/2020 Edition
23
6 ASM Software Environment
6.1 SIPLACE Pro Programming System Version 18.0
The SIPLACE Pro programming system version 18.0 supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines with the 714.0 station
software version.
Compatible mode: SIPLACE Pro 17.x
NOTICE
For a detailed description of the programming system, see the SIPLACE Pro version
description and the online help system.
6.2 ASM OIS Version 18.0
Software version 18.0 of the ASM OIS monitoring system supports the SIPLACE X-series,
X-series S, SX-series, DX-series, CA-series and TX-series placement machines.
NOTICE
A detailed description can be found in the software description "Getting started with OIS"
and the online help system for ASM OIS.
6.3 ASM Setup Center Version 9.8
Software version 9.8 of the ASM Setup Center supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: ASM Setup Center 9.7
NOTICE
A detailed description can be found in the software description "Getting started with
Setup Center" and the online help system for ASM Setup Center.
6.4 ASM Traceability Version 5.9
Software version 5.9 of ASM Traceability supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: SIPLACE Traceability 5.8
NOTICE
A detailed description can be found in the "Traceability User Guide".
Station Software 714.0 (R20-2) / Version Description 11/2020 Edition
24
7 Restrictions
For details concerning possible machine configurations, please consult the latest version of the
machine specification.
Restrictions to features in previous versions can be found in the Station Software V7xx Feature
Description, item no. [00197741-xx].
Station Software 714.0 (R20-2) / Version Description 11/2020 Edition
25
8 Corrected Errors
714.0 Station Software
The 714.0 station software version contains all error corrections of the previous 7xx versions.
Additionally, the following errors have been corrected in this version:
Error no.
Error description
G50033887
Possible crash while lane is blocked.
883_C_150520
Improvement of PRV calibration.
G50082350
Robustness eSW download.
G50098325
X4is error reason of MES not displayed on station.
G50102174
Reset data does not reset all necessary information.
T01252979
Reduce CPU usage of GUI during image acquisition (i.e. tray teaching).
T01183843
Calibration tool handling at "fast hardware exchange".
G50056864
FCU temperature error / sub-system does not answer.
G50073177
Traceability data lost during Auto Recovery.
G50098679
Data is not saved after teaching the PCB corner.
Table 8-1: Corrected errors station software version 714.0
