操作手册 I 为 了 安 全 使 用 机 器 目 目 录 录 前言 ······························································································································· ···················· S-1 熟悉名称 ····························…
iv
1.为防止人身受伤，请勿在拆下安全罩、安全装置等状态下运行。
2.为防止人身受伤，请务必小心，以免头发、衣服等被卷入传送带链。此外，请勿戴手套。
3.为防止人身受伤，维护时（加油、调试、日常检修），请切断电源。
4.为防止人身受伤，请在电源线上使用漏电断路器。
〈安全盖〉
1．开关安全盖时请注意下列事项。
• 打开安全盖时要把盖子向上开足直到上了锁，确认上了锁后再放开手。
没有上好锁就放开手时，盖子有落下来的危险。
• 关盖子时先解开锁，再关闭盖子。
（请注意，解开锁时不要使盖子落下来导致受伤。）
• 不要过度增加盖子、手把等的负荷。
1.本装置的操作系统采用 Windows XP（包括以太网通信功能）。
除安装本装置提供的软件之外，加装其他软件，不保证正常运行。对 SSD 内组装的文件进
行转移、重命名、文件夹·文件的压缩、复制，也同样不保证正常运行，敬请谅解。
● 万一出现此钟情况，需要更换新的 SSD，有可能丢失数据，务请格外注意。
为保护操作系统，使用了 Enhanced Write Filter(EWF)组件，进行了 C 盘 ROM 化。
1.请不要在 C 盘保存文件。
把文件保存在 ROM 化后的 C 盘，会仿真占用主存储器。因而，把文件存在 C 盘里时，会增加
主存储器的使用量，压迫系统。反复保存后可能造成内存不足，显示系统错误，可能需要重
启本设备。
2.需要修改 OS 信息时，必须刷新 C 盘操作。
操作方法请参见使用说明书“1－7-11 C 盘的更新操作”。
需要修改 OS 信息的操作是指下列事项：
·FX-3R 系统软件、FlexLine DB 的版本升级
·触摸屏自我校正
·添加打印机
·设置网络（IP 地址、工作组等）
·添加用户
·变更资源管理器的设置
·变更 ATX 实用程序的设置
●要变更操作系统信息时，在修改 C 盘操作后，需要重启一次本装置。
1.本装置配备有 ATX，以保护停电时的生产程序等。
为防止 ATX 内置电池劣化，请勿在非通电状态下将本装置放置 6 个月以上。
●本装置以电流总断路器及总开关 ON 的状态为通电状态。
1．X 轴、Y 龙门架轴上使用磁力线性编码器（磁性尺）。
• 不要使金属类接近磁石面，因可能被磁石吸住，金属类取不下来。
• 进行维护时，请摘下身上的手表等精密机器。
• 使用心脏起搏器等精密医疗器者，不能从事维护工作。
• 不要将带有磁石、磁力的螺丝刀等工具接近磁性尺。
• 因为支撑销使用磁石，所以请勿将其接近磁尺。
由于磁力，可能损坏磁性尺。
<轴操作保护的延迟>
本设备具有监控 X 轴及 Y 轴的温度上升，抑制温度变为异常的功能。
因此，如果在高温环境中使用，或者持续进行仅在前侧或后侧运行等对特定轴集中负荷的
操作时，将切换到插入约 0.5 秒左右的休止时间的运转状态。
为了安全使用 FX-3R 的注意事项
注意
注意
注意
注意
注意
注意
操作手册 I
为 了 安 全 使 用 机 器
目
目
录
录
前言 ··················································································································································· S-1
熟悉名称············································································································································ S-2
1 设备概要 ·······································································································································1-1
1-1 本设备的概要···················································································································1-1
1-2 本设备的构成················································································································· 1-2
1-3 操作画面 ··························································································································1-4
2 作业步骤 ·······································································································································2-1
2-1 生产的流程 ······················································································································2-1
2-2 操作概要 ··························································································································2-2
Step1 接通主机电源·······································································································2-2
Step2 执行预热··············································································································2-3
Step3 读入生产程序·······································································································2-4
Step4 选择生产画面·······································································································2-6
Step5 进行生产准备（支援准备） ·················································································2-7
支援准备 1 传送设置 ····························································································2-8
支援准备 2 确认基板传送·····················································································2-12
支援准备 3 取得外形基准位置 ·············································································2-13
支援准备 4 标记示教····························································································2-15
支援准备 5 坏板标记读入器示教··········································································2-16
支援准备 6 准备送料器 ························································································2-18
支援准备 7 吸嘴准备····························································································2-25
支援准备 8 生产前检查 ························································································2-28
Step6 执行生产············································································································2-30
Step7 结束生产画面·····································································································2-32
Step8 切断主机电源·····································································································2-33
3 生产时的各项处理 ·························································································································3-1
3-1 无元件（操作选项勾选“发生无元件暂停”时） ····························································3-1
3-2 无元件（操作选项未勾选“发生无元件暂停”时）··························································3-2
3-3
发生标记识别错误············································································································3-3
3-4 激光弄脏 ··························································································································3-4
3-5 发生错误 （激光识别错误·
・
芯片站立错误 其他生产错误） ············································3-5
3-6 吸嘴错误 ··························································································································3-7
3-7 检测到传送带浮动············································································································3-8
3-8 安全盖打开错误 ···············································································································3-9
3-9 送料器台架下降 （附带统一更换台车选购项时）··························································3-10
3-10 元件保护暂停 ···············································································································3-11
3-11 继续生产······················································································································3-12
操作手册 I
S-
1
☆
☆
前
前
言
言
本书是 FX-3R 设备的生产操作入门书。
学习本书内容，即可使用已编成的生产程序，进行基板生产。
有关制作生产程序、其他详细设置方法等内容，均收录在另册《操作手册（程序员·管理员用）、
以及附件 CD《FX-3R 使用说明书》。
● 菜单、命令等用括弧「 」标记。
菜单名连续时用 “/”标记。
例：「文件」/「打开」
● 固有名词用括弧“ ”标记。
● 键用[ ]标记。
例：[ESC]、[ENTER]
● 手册名用『 』标记。
例：『FX-3R 使用说明书』
● 有关联的复数名称用“/”标记，文字共同部分省略。
Windows 2000 及 Windows XP → Windows 2000/XP
● 第1 章 设备的概要
对本设备的构成及概要，进行介绍。
● 第2 章 作业步骤
对输入电源到生产的流程，进行说明。
● 第3 章 生产时的各项处理
对生产时发生频度较高的各种错误、原因、对策方法，进行说明。
本书是 FX-3R 设备的生产操作入门书。
本书未记述的内容，请参见附件 CD《FX-3R 使用说明书》。
本书概要
关
于
标
记
本书的构成
