Station Software 706.1 SP1/705.05 SP1 / Installation Manual Ausgabe 02/2013 Edition

4.2 SIPLACE X-, SX- and DX-Series Hardware Components

4.2.1 Machine/Vision Computer (in Two-Computer Operation)

Name SIMATIC Box PC 627

CPU / clock frequency Pentium M 760 / 2 GHz

RAM 1 GB

Hard disk Yes

External DVD drive pluggable via USB

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 4-3: Machine/Vision computer hardware SIPLACE X-series

Name SIMATIC Box PC 627B

CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz

RAM 1 GB

Harddisk Yes

External DVD drive pluggable via USB

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 4-4: Machine/Vision computer hardware SIPLACE X-series

Name SIMATIC Box PC 627C

CPU / clock frequency Intel(R) Celeron(R) P4505 / 1.87 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 4-5: Machine/Vision computer hardware SIPLACE X-series

4.2.1.1 Machine/Vision Computer with 3D Coplan Sensor

The coplanarity module with the 3D coplan sensor (type 37) can be optionally installed in the

SIPLACE X2, X3, X4 and SX1/SX2 (V2) placement machines (item no. 00119919-xx for X-series,

item no. 00519919-xx for SX-series).

Station Software 706.1 SP1/705.05 SP1 / Installation Manual Ausgabe 02/2013 Edition

4.2.2 Machine/Vision Computer (in One-Computer Operation)

Name SIMATIC Box PC 627B

CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz

RAM 1 GB (SX1/2 / DX1/2) / 2 GB (DX4)

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

A24 Hotlink cards Yes (DX4) / No (SX1/2 / DX1/2)

Table 4-6: Machine/Vision computer hardware SIPLACE SX1/SX2 and DX-series

Name SIMATIC Box PC 627C

CPU / clock frequency Intel(R) Celeron(R) P4505 / 1.87 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 4-7: Machine/Vision computer hardware SIPLACE SX1/2, DX-series

Name SIMATIC Box PC 827B

CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz

RAM 2 GB

Harddisk Yes

External DVD drive No

Internal DVD drive No

Serial interfaces 1

USB interfaces Yes

External USB hub No

Network 2x 100 MBit

Table 4-8: Machine/Vision computer hardware SIPLACE X-series and SX4

Station Software 706.1 SP1/705.05 SP1 / Installation Manual Ausgabe 02/2013 Edition

Name SIMATIC Box PC 827C

CPU / clock frequency Intel(R) Core(TM) i3 / 2.13 GHz

RAM 2 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 4-9: Machine/Vision computer hardware SIPLACE X-series
