29 SIPLACE Service SIPLACE Overall Line Effectiveness (OLE) All around the world, SIPLACE Service offers a comprehensive portfolio of services to help SIPLACE customers optimize their overall line effectiveness (OLE) - i…

SIPLACE Service

SIPLACE D-series training

SIPLACE Training for Operators

SIPLACE Preventive Maintenance Training

SIPLACE Programmer Training for SIPLACE Pro

SIPLACE Initial Training

a) Parts of the course syllabus may be skipped if you have already covered the content

SIPLACE Vision Training

SIPLACE Level 1 Training, D-series

SIPLACE Primary Training

SIPLACE Level 2 Training, D-series SIPLACE Advanced Training

SIPLACE Upgrade Training, D-series Individual SIPLACE Training Programs

The training is available in

the following languages

German, English, French,

Spanish, Portuguese,

Italian, Romanian, Bulgarian,

Czech, Russian, Polish, Hun-

garian, Slovakian, Korean,

Traditional Chinese,

Simplified Chinese,

Japanese, Thai and

Vietnamese

b) Other language available on request

SIPLACE Hotline

You can request a service engineer or order

spare parts on the SIPLACE Hotline, 24 hours

a day. It can also help you with all SIPLACE

topics.

Europe: + 49-89-20800-48642

USA: + 1-888-SMT-HELP

China: + 86-13601658385

SEA: + 65-64908822

SIPLACE Service

SIPLACE Overall Line

Effectiveness (OLE)

All around the world,

SIPLACE Service offers a

comprehensive portfolio of

services to help SIPLACE

customers optimize their

overall line effectiveness

(OLE) - in other words, to

optimize the productivity and

thus the profitability of their

line. To ensure this, the

important factors that affect

production - equipment,

employees and processes -

must interact perfectly. The

SIPLACE Service team helps

SIPLACE customers to do this,

backed up with over 20 years'

experience in the field of SMT

production. The available

services can be combined to

create solutions for individ-

ual customer requirements.

Assets

It is extremely important to

keep placement systems

(Assets) in optimum condi-

tion to ensure that produc-

tion runs smoothly.

Professional SIPLACE services

create the ideal conditions

for this.

The available services include

the following: Installation

and commissioning, main-

tenance, calibration and

restoration of machine

capability conditions,

machine status certificates,

hotline support, technical

service and services associ-

ated with upgrading and

extending existing systems.

People

The motivation and technical

skills of production em-

ployees (People) are at least

as important as the condition

of the equipment, however.

SIPLACE can provide a wide

range of training courses -

from the basic principles of

operator training through to

in-depth courses for experts.

A knowledge gap analysis

will be carried out to tailor

training programs to specific

needs. All SIPLACE training

courses can be held either in

one of 14 SIPLACE Training

Centers worldwide or on site

at the production facility

(Mobile Classroom).

Processes

Production processes (Pro-

cesses) have to be repeatedly

examined on the test bench

and matched to changing

conditions in order to guar-

antee optimum productivity

in a production facility.

SIPLACE experts will analyze

production processes on site

with the customer, identify

potentials, recommend

improvements and help

SIPLACE customers to imple-

ment them. If necessary, we

can also provide special solu-

tions for placement problems

(nozzles and grippers). This

will provide a lasting boost to

the efficiency of a production

facility.

Assets

Installation &

Commissioning

Maintenance Support

Upgrades &

Options

People

SIPLACE Knowledge

Gap Analysis

SIPLACE Training Process Training

Processes

Customization

Services

Performance

Services

01005 Placement

The SIPLACE D4 is prepared

to place 01005 components

(0.4 mm x 0.2 mm) as stan-

dard. To do this, you simply

have to implement the optio-

nal 01005 package for

12-nozzle Collect&Place

heads. You can then easily

process even the tiniest com-

ponents currently available

with no drop in output.

For 01005 placement you

will need station software

version 604.01 and SIPLACE

Pro 5.0 (or a later version).

This will also improve the

detection capability at the

associated nozzles.

The 01005 package for the

SIPLACE D-series contains the

following components:

• Sleeves for placement

with low placement forces

(3x)

• High-resolution camera ,

type 38

• Special type 905 nozzles

designed for 01005 place-

ment (12 x)

There are also special S

feeder modules available for

01005 placement. These

optimize pick-up by ensuring

the ideal feeding conditions.

As a rule with 01005 place-

ment, a finely tuned overall

01005 process is the basic

requirement if you want to

achieve excellent results.

All the process parameters

must be optimized. The

SIPLACE team will be pleased

to advise you on how to do

this.

01005 measurement

results and ambient condi-

tions

Dpm values and pick-up rates

for 01005 placement are

highly dependent on the

measuring conditions, so it is

important to specify them

with the corresponding

ambient conditions. Ask your

local SIPLACE dealer for

examples and the associated

conditions.
