33 Technical Data Electrical Connection, Interfaces and Compressed Air Connection Compressed air connection SMEMA/Siemens interface PC and LAN connection Power connector 5 x 6 mm² cable with CEKON plug 5 x 32 A (3 x 208 …
32
Technical Data
Electrical Ratings and Compressed Air Supply
Electrical ratings
Supply voltage 3 x 200 VAC ± 5 %; 50/60 Hz (Japanese version)
3 x 208 VAC ± 5 %; 50/60 Hz (U.S.A. version)
3 x 230 VAC ± 5 %; 50/60 Hz
3 x 380 VAC ± 5 %; 50/60 Hz
3 x 400 VAC ± 5 %; 50/60 Hz (European version)
3 x 415 VAC ± 5 %; 50/60 Hz
Fuses 3 x 32 A (3 x 200 VAC / 3 x 208 VAC / 3 x 230 VAC)
3 x 16 A (3 x 380 VAC / 3 x 400 VAC / 3 x 415 VAC)
Nominal apparent power 3.3 kVA
Rated current consumption 8.2 A / 3 x 400 VAC
Compressed air supply
Compressed air ratings
p
min
p
max
0.55 MPa = 5.5 bar
1.0 MPa = 10 bar
Compressed air connection R 3/4" internal thread (pipe thread) with
1/2" hose connector
Compressed air consumption with four
tape cutters and four C&P heads
a
a) Under normal atmospheric conditions at 20°C and 1013 hPa
950 Nl/min
400 Nl/min with vacuum pump
Operating pressure 0.51 MPa ± 0.01 MPa (5.1 bar ± 0.1 bar)
Compressed air specification
Particle size 5 µm ISO class 3
Particle density 5 mg/m³ ISO class 3
Maximum oil content 0,01 mg/m³ ISO class 1
Pressure dewpoint + 3°C ISO class 4
33
Technical Data
Electrical Connection, Interfaces and
Compressed Air Connection
Compressed air connection
SMEMA/Siemens interface
PC and
LAN connection
Power connector 5 x 6 mm² cable with CEKON plug 5 x 32 A (3 x 208 VAC / 3 x 230 VAC)
5 x 4 mm² cable with CEKON plug 5 x 16 A (3 x 380 VAC / 3 x 400 VAC / 3 x 415 VAC)
34
Technical Data
Dimensions and Set-up Conditions
Length of the basic machine
with both extension kits
with one extension kit
with no extension kit
2380 mm
1960 mm
1540 mm
Width of the basic machine
with component changeover table
including monitors
with keyboards
2416 mm
2466 mm
2491 mm
Height of the machine
with indicator lamp
with folded-up protective covers
max. 1813 mm
1850 mm (PCB conveyor height 830 mm)
1920 mm (PCB conveyor height 900 mm)
1950 mm (PCB conveyor height 930 mm)
1973 mm (PCB conveyor height 950 mm)
Machine ground clearance 110 mm (PCB conveyor height 830 mm)
180 mm (PCB conveyor height 900 mm)
210 mm (PCB conveyor height 930 mm)
233 mm (PCB conveyor height 950 mm)
Weight
Basic machine with 4 CO changeover tables
Full configuration with feeder modules
3419 kg
3850 kg
Footprint 5.93 m²
Load per unit area
a
a) The load per unit area calculation included an additional working space of 0.5 m on each side of the
machine. Further data available on request.
5.9 kN/m²
Number of machine feet 6
Maximum noise emissions 74 dB (A)
Room temperature between 15 °C and 35 °C
Atmospheric humidity 30 to 75 % (no higher than 45% on aver-
age to prevent any possibility of conden-
sation on the machine)
