FlexTRAK Series 2MB Electrode Fixturing Addendum Parts Replacement
© 2023 Nordson Corporation 5
3.5 Exploded Views
This section contains lists of item numbers corresponding to the part description.
Review the spare parts kits Excel file for the item number referencing the part number
when ordering replacement parts for the FlexTRAK Series 2MB Electrode Fixturing
Assembly. Contact March Technical Support for questions.
Table 3-1 Spare Parts List
Item No. Description
1 ELECTRODE PLATE
2 ELECTRODE STANDOFF
3 ELECTRODE STANDOFF
4 ELECTRODE PLATE
5 ELECTRODE STANDOFF
6 ELECTRODE STANDOFF
7 ELECTRODE PLATE
8 ELECTRODE STANDOFF
9 ELECTRODE STANDOFF
FlexTRAK Series 2MB Electrode Fixturing Addendum Parts Replacement
6 © 2023 Nordson Corporation
The callouts in Figure 3-1 through Figure 3-4 correspond to the item numbers in
Table 3-1.
Item Description
1 ELECTRODE PLATE
2 ELECTRODE STANDOFF
3 ELECTRODE STANDOFF
Figure 3-1 Aluminum Electrode Fixturing Assembly for 75mm-Process Carrier
2
1
2
3
FlexTRAK Series 2MB Electrode Fixturing Addendum Parts Replacement
© 2023 Nordson Corporation 7
Item Description
4 ELECTRODE PLATE
5 ELECTRODE STANDOFF
Figure 3-2 Aluminum Electrode Fixturing Assembly for 136mm-Process Carrier
Item Description
6 ELECTRODE STANDOFF
Figure 3-3 Ceramic Electrode Fixturing Assembly for 136mm-Process Carrier
5
4
5
