Support M edia V1. 14 11/2012 Edit ion 14 Release R30 R40 SuP40 R50 SuP50 Support M edia V1.8 V1.9 V1.11 V1.12 V1.13 V1.14 W indows Im aging Compon ent * * Active S ync 3.7.1 X X X X - - Active S ync 4.5 X X X X - - W in…
Support Media V1.14 11/2012 Edition
13
Release R30 R40 SuP40 R50 SuP50
Support Media
V1.8 V1.9 V1.11 V1.12 V1.13 V1.14
SQL 2008 SP 1 Express
1
X X - - - -
SQL 2008 SP 1 Express
Update
1
X X X X - -
SQL 2008 SP 2 Express Update X X X *
SQL 2008 SP 3 Express Update X X X X
SQL 2008 R2 Express with
Tools
X * *
SQL 2008 R2 SP 1 Express with
Tools
X *
SQL 2008 R2 SP 1 Express
Update
X *
SQL 2008 R2 SP 2 Express with
Tools
X
SQL 2008 R2 SP 2 Express
Update
X
SQL 2012 Express with Tools *
SQL Server 2005 SP 1 Update
X X * *
SQL Server 2005 SP 2 Update
X X * *
SQL Server 2005 SP 3 Update X X * *
SQL Server 2005 SP 4 Update X * *
SQL Server 2008 SP 1 Update
1
X X X X - -
SQL Server 2008 SP 2 Update X X * *
SQL Server 2008 SP 3 Update
* *
SQL Server 2008 R2 SP 1
Update
* *
SQL Server 2008 R2 SP 2
Update
* *
1
We had to modify this package and integrate the cumulative update KB977443. This was required
for proper installation on Windows 7 / Windows Server 2008R2. Also see
http://support.microsoft.com/?id=kb;en-us;975055
for a description of the problem.
Support Media V1.14 11/2012 Edition
14
Release R30 R40 SuP40 R50 SuP50
Support Media
V1.8 V1.9 V1.11 V1.12 V1.13 V1.14
Windows Imaging Component * *
Active Sync 3.7.1 X X X X - -
Active Sync 4.5 X X X X - -
Windows Mobile Device Center
6.1
X X X X - -
WinHlp32 Hotfix for
Vista/W2008
X X X X - -
PowerShell V1 for
XP/W2003/Vista
X X X X * *
PowerShell V2 for Vista/W2008 *
Support Media V1.14 11/2012 Edition
15
3.4 Download of required but not distributed Software
Due to the fact, that not all required software packages from other vendors can be redistributed by
ASM Assembly Systems, Support Media Prerequisite Analyzer offers multiple ways of downloading
and installing missing software components.
CAUTION
Legal changes regarding redistribution
The redistribution right is affecting the delivery through digital media like DVD as
well as manual delivery through ASM Assembly Systems personnel.
The following chapter describes the available options exemplarily.
3.4.1 Download options of Prerequisite Analyzer
In Prerequisite Analyzer on the Pending Actions Summary page, before installation of Prerequisites
takes place, the media will be checked for the availability of all required Software packages. If at
least one of the required packages is missing, you will get one of the following two dialogs, with the
options sorted by relevance. In this chapter, we give you a basic overview of the options available.
Figure 3-1: Unavailable Installation Packages – No Additional Software Search Folder defined
► Click the Specify Search Folder button to select a (local) folder to search for missing Software
packages.
► Click the button Download and install manually to show the list of missing Software Packages
together with information and links for manual download and installation.
► Click the button Download offline if you don’t have web- access from your computer and want
to download the missing packages using another computer with web- access.
