Support M edia V1. 14 11/2012 Edit ion 49 Printer S haring rules ins tead COM + Applic atio n SIPLAC E Line Control (DCOM In) %system32%\ syste m32 \dllhost.ex e (for %Pro gram Files% \ S IP LA C E \ SIPL ACE Pro \ LCDS …

100%1 / 63
Support Media V1.14 11/2012 Edition
48
Application
SIPLACE
Line
Control
(SOAP
HTTP
Out)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
<Don’t filter
service name –
doesn’t work>
Outbound
TCP(
HTTP
)
49001
Allow access
to the Station
via HTTP
protocol
Application
SIPLACE
Line
Control
(SOAP
TCP Out)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
<Don’t filter
service name –
doesn’t work>
Outbound
TCP
49002
Allow access
to the Station
via TCP
protocol
Application
SIPLACE
Line
Control
(SOAP
HTTP In)
%Program Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe
<Don’t filter
service name –
doesn’t work>
Inbound
TCP(
HTTP
)
49003
Allow access
to the Line
Control
Server via
HTTP
protocol
Application
SIPLACE
Line
Control
(SOAP
TCP In)
%Program Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe
<Don’t filter
service name –
doesn’t work>
Inbound
TCP
49004
Allow access
to the Line
Control
Server via
TCP protocol
Application
SIPLACE
Line
Control
(SOAP
HTTP Out
to Setup
Center)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
<Don’t filter
service name –
doesn’t work>
Outbound
HTTP
49041
Allow access
to the Setup
Center via
HTTP
protocol
net use
SIPLACE
Line
Control
(net use)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
N/A
Outbound
NetBi
os
Proto
col
139 / 445
Used to write
Files onto some
Stations via
Network Share
Note: this rule
is not required
– we use the
built- in File and
Support Media V1.14 11/2012 Edition
49
Printer Sharing
rules instead
COM +
Application
SIPLACE
Line
Control
(DCOM
In)
%system32%\system32\dllhost.exe
(for %Program
Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe)
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access
to the
SIPLACE Pro
Line Control
Server via
DCOM
protocol for
32 Bit host
system
COM +
Application
SIPLACE
Line
Control*
(DCOM
In)
%system32%\SysWOW64\dllhost.exe
(for %Program
Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe)
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access
to the
SIPLACE Pro
Line Control
Server via
DCOM
protocol for
64 Bit host
system
COM +
Application
SIPLACE
Line
Control
Server
(RPC In)
%Program Files%\SIPLACE\SIPLACE
Pro\LCSVR.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow RPC
access to Line
Control
Server
COM +
Application
SIPLACE
Line
Control
Dispatche
r (RPC In)
%Program Files%\SIPLACE\SIPLACE
Pro\LCDSVR.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow RPC
access to Line
Control
Dispatcher
You can freely configure network shares in the Line Control GUI Configuration (SIPLACE OS and Recipe Analyzer), which will be used by Line Control.
Support Media V1.14 11/2012 Edition
50
4.1.22 SetupCenter (SetupCenter.exe and SetupCenterServer.Service.exe)
POC: Ekrem Aktas
The following rules are especially for Windows XP / Windows Server 2003 / Windows 7:
SetupCenter.exe
XP/W2003/W7
Rules
Name of the Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Service
SIPLACE Setup
Center Server
%ProgramFiles%\
SIPLACE\
SetupCenterService\
SetupCenterServer.Service.exe
N/A
Inbound
ANY
ANY
Allow inbound
communication
to
SetupCenterSe
rver.Service.ex
e
Application
SIPLACE Setup
Center
%ProgramFiles%\
SIPLACE\
SetupCenter\SetupCenter.exe
N/A
Inbound
ANY
ANY
Allow inbound
communication
to
SetupCenter.ex
e
4.1.23 Resources used by SIPLACE License manager application
POC: Axel Schröppel
The following rules are especially for Windows XP / Windows Server 2003:
SIPLACE Pro
Server
XP/W2003
Rules
Name of the
Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE
License
%Program Files%\SIPLACE\SIPLACE
Licensemanager2\
N/A
Inbound
Any
All
Allow access to
License Host
