Support Media V1.14 11/2012 Edition
56
4.1.26 OIS / Monitoring Service
POC: Juergen Schmitt
The following rules are especially for Windows XP / Windows Server 2003 / Windows 7:
SetupCenter.exe
XP/W2003/W7
Rules
Name of the Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Service
SIPLACE OIS
Monitoring Service
(Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Monitoring Service\
MonitoringService.exe
Monitor
ingServ
ice
Inbound
HTTP
51001
SSI.Messages
Service
SIPLACE OIS OIS
Server (Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Monitoring Service\
OisServer.exe
OisSer
ver
Inbound
HTTP
52052
Ois-
MonitoringConv
erter
Application
SIPLACE OIS Client
(DCOM)
%ProgramFiles%\
Ois\
OisClient.exe
N/A
Inbound
DCOM
DCOM
Range
Data Exchange
with Data
process
Application
SIPLACE OIS Buffer
(DCOM)
%Program Files%\
Ois\
OisData.exe
N/A
Inbound
Outbound
DCOM
DCOM
Range
Buffer process
for OisClient
Support Media V1.14 11/2012 Edition
57
4.1.27 Line Shortage Tracker / LED Pairing Controller
POC: Juergen Schmitt
The following rules are especially for Windows XP / Windows Server 2003 / Windows 7:
SetupCenter.exe
XP/W2003/W7
Rules
Name of the Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Service
SIPLACE LST Pairing
Controller (Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Led Pairing
Controller\
LedPairingController.exe
Inbound
TCP
TCP
HTTP
1666
1667
33334
LstControlPort
LstDiagnosisPort
BGK:BoardNotifications
Application
SIPLACE LST Viewer
(Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Led Pairing
Controller\
LedPairingControllerViewer
.exe
Inbound
TCP
1655
LstViewerPort
Application
SIPLACE LST Tool
(Soap In)
%ProgramFiles%\
SIPLACE\
SIPLACE Led Pairing
Controller\
LedPairingTray.exe
Inbound
TCP
1655
DecisionRequestLauncher
4.1.28 SIPLACE Explorer
POC: Manfred Taube
Support Media V1.14 11/2012 Edition
58
Component
Name of the Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Service
SIPLACE Tomcat.exe
%ProgramFiles%\
Apache Software
Foundation\Tomcat
5.5\bin\tomcat5.exe
(as defined by user during
setup via SupportMedia)
Inbound
HTTP
8080
(as
defined
by user
during
setup
via
Suppor
tMedia)
Access to SIPLACE
Explorer Websites
Service
SIPLACE SiEx.exe
%ProgramFiles%\
SIPLACE
Explorer\SiEx.exe
Inbound
TCP
1099,
1100,
1101,
1102
Access to SIPLACE
Explorer runtime via Java
RMI.
Application
SIPLACE Tomcatw.exe
%ProgramFiles%\
Apache Software
Foundation\Tomcat
5.5\bin\tomcat5w.exe
(as defined by user during
setup via SupportMedia)
Inbound
TCP
1099,
1100,
1101,
1102
Java RMI.
Application
SIPLACE javaw.exe
%ProgramFiles%\
Java\jre6\bin\javaw.exe
Inbound
TCP
1099,
1100,
1101,
1102
Java RMI.
