Station Software 605.03 SP5 / Installation Manual Ausgabe 11/2013 Edition
16
4.3 SIPLACE D1 / D1i, D2 / D2i, and D4 / D4i Hardware Components
NOTICE
The machine computer and Vision computer software can optionally be used in one-
computer operation on a Box PC 627B/627C or an I-Base ABP102-A.
4.3.1 Station Computer
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-8: Station computer hardware (SIPLACE D-series)
4.3.2 Machine Controller
Name SIMATIC Microbox 420
CPU / clock frequency Pentium III / 933 MHz
RAM 256 MB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-9: Machine controller hardware (SIPLACE D-series)
Station Software 605.03 SP5 / Installation Manual Ausgabe 11/2013 Edition
17
4.3.3 Machine/Vision Computer (in One-Computer Operation)
Name SIMATIC BoxPC 627B
CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz
RAM 1 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and
external USB hub
Yes
Network 2x 100 MBit
Table 4-10: Machine/Vision computer hardware (SIPLACE D-series)
Name SIMATIC BoxPC 627C
CPU / clock frequency Intel(R) Celeron(R) P4505 / 1,87 GHz
RAM 1 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-11: Machine/Vision computer hardware (SIPLACE D-series)
Name I-Base ABP102-A
CPU / clock frequency Celeron® Dual Core T3100 / 1,9 GHz
RAM 2 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 1000 MBit
Table 4-12: Machine/Vision computer hardware (SIPLACE D-series)
Station Software 605.03 SP5 / Installation Manual Ausgabe 11/2013 Edition
18
4.4 SIPLACE CA-Series Hardware Components
NOTICE
The hardware
configuration of the station computer and the optional Vision computer can
only be combined with a particular hardware configuration for the machine controller.
See the following table for details.
Station computer Machine controller Vision computer
(with 3D coplanarity sensor
option)
SIMATIC Box PC 627 SIMATIC Box PC 627 SIMATIC Box PC 627
4.4.1 Station Computer
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-13: Station computer hardware (configuration of SIPLACE CA-series)
4.4.2 Machine Controller
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-14: Machine controller hardware (configuration of SIPLACE CA-series)
