Station Software 605.03 SP5 / Installation Manual Ausgabe 11/2013 Edition
43
► Click the Finish button.
NOTICE
To establish the connection between the Vision computer and the machine controller
after installation has been completed, the Vision computer, machine controller and
station computer must first be run down and the machine must then be switched off
completely.
► To do this, open the Start menu and select Programs SIPLACE
Shutdown_Vision_MC_SR (all).
Figure 7-4: Shutting down the station computer, machine controller and Vision computer
► Switch the machine off when the computer systems have shut down.
► Switch the machine back on again. This then reboots the Vision computer, the machine
controller and the station computer.
Station Software 605.03 SP5 / Installation Manual Ausgabe 11/2013 Edition
44
8 Uninstalling the Vision Computer Software
If it is necessary to uninstall the Vision computer software manually, this must be done in one of the
ways described below.
NOTICE
You must be logged in as administrator to uninstall the software.
► Open the Start menu and choose Programs VISIONPC VISIONPC Uninstall.
Figure 8-1: Starting uninstallation (alternative 1)
Or:
► Open the Start menu and choose Settings Control Panel.
► Double-click Add/Remove Programs.
Figure 8-2: Starting uninstallation (alternative 2)
► Select VISIONPC from the list of installed programs.
► Click the Change/Remove button.
Station Software 605.03 SP5 / Installation Manual Ausgabe 11/2013 Edition
45
Figure 8-3: Finalizing uninstallation
► Click the Finish button.
The Vision computer software has now been uninstalled correctly.
