Copyright ⓒ 201 7 Hanwha Precision M achinery Co., Ltd. a ll rights reserved. Item SM471 PLUS SM481 PLUS SM482 PLUS Spindle / Gantry 10 Spindles × 2 Gantry 10 Spindles × 1 Gantry 6 Spindles x 1 Gantry Speed (Optimum / IP…
Copyright ⓒ 2017 Hanwha Precision Machinery Co., Ltd. all rights reserved.
Summary
Performance
Preview
Reliability
Flexible
Production
Easy
Operation
Comparison
Accessories
l Structure 1 Gantry x 6 spindles/Head
l Speed 30,000 CPH (Optimum)
l Accuracy ±40㎛ Cpk≥1.0 (0402)
±30㎛ Cpk≥1.0 (IC, Fix Camera)
l Parts Size 0603 ~ □22mm, H12mm (Fly Cam.)
~ □55mm, L75mm, H15mm (Fix Cam. , Option)
l PCB Size: Max. 460 x 400 (Standard)
Max. 740 x 460 (Option)
SM482 PLUS: Multi-Functional Placer
▌High Performance
- 更改X、Y轴马达:速度相比于SM482提高了7%
▌High Reliability
- 利用Fly Camera检查吸嘴状态
- Accuracy: ±40um, Cpk≥1.0 (0402)
▶ SM482: ±50um, Cpk≥1.0 (0402)
▌Flexible Production
- 可应对PCB尺寸: L740 x W460mm
Max. (L)1,200 x (W)460 (预定适用到2017.05为止)
▌Easy Operation
- 可以混合使用气压式/电动式供料器
- 改善MMI功能
NPE, Panorama View, Multi-Vendor
Copyright ⓒ 2017 Hanwha Precision Machinery Co., Ltd. all rights reserved.
Item
SM471 PLUS
SM481 PLUS
SM482 PLUS
Spindle / Gantry
10 Spindles×2 Gantry
10 Spindles×1 Gantry
6 Spindles x 1 Gantry
Speed
(Optimum / IPC9850)
78,000 CPH
/ 60,000 CPH
40,000 CPH
/ 32,000 CPH
30,000 CPH
/ 25,000 CPH
Accuracy
(Cpk≥1)
Chip
±40㎛
±40㎛
IC
-
±30㎛
Applicable
Component
(mm)
Size
0402 ~ □14
0402 ~ □16
(Option : ~□42)
0603 ~ □55
(Option : 0402)
Height
12
10 (Option : 15)
12 (Option : 15)
Conveyor System
Dual Lane
Single Lane
Max. PCB (L×W, mm)
510×460
610×460 (Option)
460×400
740×460 (Option)
Feeder Slot (8mm Tape)
120 Slots (Docking Cart : 112 Slots)
Dimension (L×W×H, mm)
1,650×1,690×1,485
1,650×1,680×1,530
Performance
Preview
Reliability
Flexible
Production
Easy
Operation
Comparison
Accessories
SM400 PLUS系列设备规格对比
SM400 PLUS Series Chip Mounter
Copyright ⓒ 2017 Hanwha Precision Machinery Co., Ltd. all rights reserved.
▌SM471 PLUS
- 2个悬臂，每个悬臂有10个轴杆
- 个轴杆Pitch:15mm
. 同时吸取时的元器件尺寸 : □8mm以下
. 只有2,4,6,8,10号轴杆同时吸取时的元器件尺寸
□8mm以上, □14mm以下
- 可贴装的元器件范围:03015~□14mm(飞行相机)
两个主轴共用一个相机
飞行相机的像素分辨率
- SM471 PLUS (FOV 24 mm): 0.023 mm/pixel
- SM481 PLUS (FOV 24 mm): 0.023 mm/pixel
Performance
Preview
Reliability
Flexible
Production
Easy
Operation
Comparison
Accessories
Head特点
轴杆转动时,
▌SM481 PLUS
- 1个悬臂，每个悬臂有10个轴杆
- 个轴杆Pitch:15mm
. 同时吸取时的元器件尺寸 : □8mm以下
. 只有1,3,5,7,9号轴杆同时吸取时的元器件尺寸
□8mm以上, □16mm以下
- 可贴装的元器件范围:0402~□16mm(飞行相机)
SM400 PLUS Series – Head特点 / Camera特点
