Changing the Feeder ID on the EEPROM

Attaching /Removing Labels

46 Nachrüstanleitung / Retrofit Instructions Feeder Module 3x8 mm S 0201/0402 to

8.5 Attaching /Removing Labels

The conversion turns the 3x8 mm feeder into a shutterless feeder. This change needs to be documented

on the back of the device, so that the information can be seen when the feeder is in production, on a

changeover table.

X Stick the label provided in the retrofit kit - with the shutterless feeder item number (00141088-01) -

over the old label on the operating panel of the feeder, as shown in the diagram.

NOTE:

If you have converted the feeder back from a shutterless feeder to a conventional S feeder,

carefully (!) remove the shutterless feeder ID label again.

When removing the label, take care not to damage the old label with the S feeder item number

(00141098-01).
