SIPLACE Explorer 2.11 Ausgabe 10/2013 Edition 1.2 Machines Supported by SIPLACE Explorer V2.11 SIPLACE Explorer V2.11 has been specially develop ed fo r the monitoring of production with the following machines: ● SIPLACE…
SIPLACE Explorer 2.11 Ausgabe 10/2013 Edition
1.1.1
1.1.2
1.1.3
Runtime Environment
Runtime Environment is specially tailored to the execution requirements of line monitoring applications for
production lines in the production environment. Several Development Environment tools are also required
in the production environment and these are supported by Runtime Environment. Runtime Environment
runs as a Windows NT service and is automatically started when you boot your computer. You can
configure and execute SIPLACE Explorer applications in Runtime Environment.
Runtime Environment facilitates the execution of multiple line monitoring applications and therefore allows
several production lines to be monitored at the same time. The start and stop times for monitoring
individual production lines can be independently configured.
Factory Configuration Utility
If you want to work with Factory Reporting, you will also need to install the option "Factory Configuration
Utility". The following functions will then be available:
● Overview of all production lines during production
● The factor website is the so-called "single entry point" for all line websites i.e. you can click your way
through to all other line websites from the factory website.
● Factory reporting
● Central organization of User Management
Development Environment
NOTICE
Development Environment
The Development Environment is not needed for normal operation of SIPLACE Explorer.
This is an expert tool, required for adaptation of websites etc.
Development Environment is an independent application which supports all tools and utilities from
SIPLACE Explorer V1.2.
This application can be used as follows:
● Development of SIPLACE Explorer applications
● Configuration of line monitoring applications from the installed SIPLACE Explorer applications
● Creation of templates for SIPLACE Explorer applications
● Execution of the created line monitoring applications
Please note that the online monitoring of board production should be performed with Runtime
Environment.
Basic developer skills are required for working with Development Environment.
6 of 48
SIPLACE Explorer 2.11 Ausgabe 10/2013 Edition
1.2 Machines Supported by SIPLACE Explorer V2.11
SIPLACE Explorer V2.11 has been specially developed for the monitoring of production with the following
machines:
● SIPLACE HF
● SIPLACE HF/3
● SIPLACE HS-60
● SIPLACE HS-50+
● SIPLACE HS-50
● SIPLACE X2
● SIPLACE X3
● SIPLACE X4
● SIPLACE 80 F4
● SIPLACE 80 F4-6
● SIPLACE F5
● SIPLACE F5HM
● SIPLACE 80 S-20
● SIPLACE S-23
● SIPLACE S-25HM
● SIPLACE S-27 HM
● SIPLACE CS
● SIPLACE CF
● SIPLACE D3
● SIPLACE D4
● SIPLACE D2
● SIPLACE D1
● SIPLACE X4I
● SIPLACE DX1
● SIPLACE DX2
● SIPLACE DX4
● SIPLACE SX1
● SIPLACE SX1 V2
● SIPLACE SX2
● SIPLACE SX2 V2
● SIPLACE X2 S
● SIPLACE X3 S
7 of 48
SIPLACE Explorer 2.11 Ausgabe 10/2013 Edition
● SIPLACE
SX4
● SIPLACE X4i S
● SIPLACE X4 S
● SIPLACE X4 S micron
NOTICE
SIPLACE D1/D2
Machines of type SIPLACE D1 and D2 are only supported from SW 603 and SIPLACE
Pro 4.1 onwards. However, SIPLACE Explorer supports these machine types from
version 2.1. onwards.
The standard SIPLACE Explorer 2.11 delivery package supports the above listed SIPLACE machines.
SIPLACE Explorer can also be used with other line components (e.g. screen printers and reflow ovens)
and for the evaluation of production performance with the Standard Monitoring Application (SMA) or other
applications.
For detailed information about special components and interfaces, please contact your regional SIPLACE
sales partner.
