Type L max mm [in] L 1 * mm [in] L 2 mm [in] OMT 160 190 [7.48] 16.5 [0.650] 140 [5.51] OMT 200 195 [7.68] 21.5 [0.846] 145 [5.71] OMT 250 201 [7.91] 27.8 [1.094] 151 [5.94] OMT 315 211 [8.31] 37.0 [1.457] 161 [6.34] OMT…

100%1 / 33
Standard flange—US version
Ø127.00 [5.000]
Ø126.95 [4.998]
Ø123.8 [4.874]
Ø122.2 [4.811]
Ø86.5 [3.406]
Ø85.5 [3.366]
73.7 [2.902]
71.5 [2.815]
64.5 [2.539]
63.5 [2.500]
33.15 [1.305]
30.85 [1.215]
18 [0.71]
23.6 [0.929]
22.4 [0.882]
60 [2.36]
R0.8 [0.003]
max. 69 [2.72]
Ø162.3 [6.390]
Ø161.5 [6.358]
9 [0.35]
22.4 [0.882]
31 [1.22]
max. 75 [2.95]
max. 67 [2.64]
R12.5 [0.492]
Ø14 [0.55]
max. 143 [5.63]
151-889.11.22
20.3 [0.799]
19.7 [0.776]
20.3 [0.799]
19.7 [0.776]
100 [3.94]
max. 128 [5.04]
C
D
L
L
1
L
2
L
3
max. 143 [5.63]
C: Drain connection 9⁄16 - 18 UNF; 13 mm [0.51 in] deep O-ring boss port
D: 1 1⁄16 - 12 UN; 19 mm [0.75 in] deep O-ring boss port
Technical Information
OMS, OMT and OMV Orbital Motors
OMT
520L0407 • Rev 0601 • February 2016 63
Type L
max
mm [in] L
1
*
mm [in] L
2
mm [in]
OMT 160 190 [7.48] 16.5 [0.650] 140 [5.51]
OMT 200 195 [7.68] 21.5 [0.846] 145 [5.71]
OMT 250 201 [7.91] 27.8 [1.094] 151 [5.94]
OMT 315 211 [8.31] 37.0 [1.457] 161 [6.34]
OMT 400 221 [8.70] 47.5 [1.870] 171 [6.73]
OMT 500 235 [9.25] 61.5 [2.421] 185 [7.28]
*
The gearwheel set is 3.5 mm [0.138 in] wider across the rollers than the L1 dimensions
Output shaft L
3
mm [in]
Cyl. 1.5 in
Splined 1.5 in
82 [3.23]
Tapered 1.75 in 80.4 [3.17]
Technical Information OMS, OMT and OMV Orbital Motors
OMT
64 520L0407 • Rev 0601 • February 2016
Wheel—European version
Ø126.25 [4.970]
Ø123.75 [4.872]
Ø123.8 [4.874]
Ø122.2 [4.811]
Ø172.000 [6.7717]
Ø171.937 [6.7692]
Ø160.000 [6.2992]
Ø159.937 [6.2967]
Ø73 [2.87]
Ø71 [2.80]
2 [0.08]x45˚
4 [0.16]
18 [0.71]
7 [0.28]
23.6 [0.929]
22.4 [0.882]
13.0 [0.512]
12.0 [0.472]
13.0 [0.512]
12.0 [0.472]
13.0 [0.512]
12.0 [0.472]
13.0 [0.512]
12.0 [0.472]
99 [3.90]
78.2 [3.079]
82 [3.23]
R1.2 [0.047]R1.2 [0.047]
45˚
Ø200.4 [7.890]
Ø199.6 [7.858]
8 [0.31]
90.3 [3.555]
98.2 [3.866]
max. 69 [2.72]
22.1 [0.870]
21.1 [0.831]
22.1 [0.870]
21.1 [0.831]
max. 67 [2.64]
75 [2.95]
max. 71 [2.80]
22.1 [0.870]
21.1 [0.831]
22.1 [0.870]
21.1 [0.831]
20.3 [0.799]
19.7 [0.776]
20.3 [0.799]
19.7 [0.776]
R16 [0.63]
Ø18 [0.71]
max. 180 [7.09]
max. 180 [7.09]
151-897.12
100 [3.94]
max. 128 [5.04]
C
E
D
L
L
1
L
2
C: Drain connection
G 1⁄4; 12 mm [0.47 in] deep
D: M10; 10 mm [0.39 in] deep E: G 3⁄4; 17 mm [0.67 in] deep
Type L
max
mm [in] L
1
*
mm [in] L
2
mm [in]
OMTW 160 123 [4.84] 16.5 [0.650] 73 [2.87]
OMTW 200 128 [5.04] 21.5 [0.846] 78 [3.07]
Technical Information OMS, OMT and OMV Orbital Motors
OMT
520L0407 • Rev 0601 • February 2016 65
