Sequential System of Wiring Diagram and How to Issue Order.
1. Sequential system
Diagram is constructed to cover items in order of contents and
wiring diagram.
EJM1A-904E
EJM1A-903E
Wiring diagram
Contents
2. How to issue order.
Adopt the following step in issuing order in accordance with
article No. of parts for issued order.
1． Search for the required wiring diagram from the drawing No. on the
contents.
(Contents)
(Wiring diagram)
EJM1A-901E
EJM1A-902E
N610001696AA - E0040-01
See contents.
See wiring diagram.
A
rticle No. of pertinent parts
for issued order.
2． When placing an order for cables, please let us know their numbers on
the wiring diagram.
There are two methods of finding part numbers.
<Example of issuing order>
∗
Case 1
When placing an order for cables, please let us know their numbers in
the mark or on the wiring diagram.
Order number
Example c
Example d
Part numbers on the wiring diagram (in alphanumerics)
EJM1A-905E
KXF
P6ER7
c
KXF P6ER7
d
N51 0006032 AA
N51000
6032AA
