MACHIN E PC REAR PANEL CONNECTOR FUNCTIONS 5.18 Technical Reference Manual Chapter Issue 1 S ep 02 Mouse Port 3SK07 (6 W ay Mini-DIN) Ethernet UTP Connector 3SK02 (8 W ay RJ45) USB Connectors 0,1, 2 & 3 3SK34, 35, 36…

100%1 / 20
MACHINE PC
REAR PANEL CONNECTOR FUNCTIONS
Chapter Issue 1 Sep 02 Technical Reference Manual 5.17
PCA-6180 ISA 2/3
Video Connector 3SK05 (15 Way Condensed D Type)
RS232 Touchscreen COM 1 3PL03 (9 Way D Type)
Keyboard Port 3SK04 (6 Way Mini-DIN)
PIN 39 DIG.IN.7 PIN 39 DIG.IN.10
PIN 40 DIG.IN.9 PIN 40 DIG.IN.8
PIN 41 DIG.IN.11 PIN 41 DIG.IN.14
PIN 42 DIG.IN.13 PIN 42 DIG.IN.12
PIN 43 DIG.IN.15 PIN 43 DIG.IN.18
PIN 44 DIG.IN.17 PIN 44 DIG.IN.16
PIN 45 DIG.IN.19 PIN 45 DIG.IN.22
PIN 46 DIG.IN.21 PIN 46 DIG.IN.20
PIN 47 DIG.IN.23 PIN 47 GND
PIN 48 +5V O/P PIN 48 GND
PIN 49 +5V O/P PIN 49 RELAY NO
PIN 50 RELAY N/C PIN 50 RELAY COM
Pin No. Signal Pin No. Signal
1 Analog Red 9 Not Used
2 Analog Green 10 0 Volts (GND)
3 Analog Blue 11 Not Used
4 Not Used 12 Not Used
5 0 Volts (GND) 13 Horizontal Sync
6 0 Volts (GND) 14 Vertical Sync
7 0 Volts (GND) 15 Not Used
8 0 Volts (GND)
Pin No. Signal Pin No. Signal
1 Data Carrier Detect 6 Data Set Ready
2 Receive Data 7 Ready To Send
3 Transmit Data 8 Clear To Send
4 Data Terminal Ready 9 Ring Indicator or Power
5 Ground
Pin No. Signal Pin No. Signal
1 Keyboard Data 4 +5Volts (Fused)
2 Not Used 5 Keyboard Clock
3 Ground 6 Not Used
Connector 3SK12 Left Row Connector 3SK12 Right Row
MACHINE PC
REAR PANEL CONNECTOR FUNCTIONS
5.18 Technical Reference Manual Chapter Issue 1 Sep 02
Mouse Port 3SK07 (6 Way Mini-DIN)
Ethernet UTP Connector 3SK02 (8 Way RJ45)
USB Connectors 0,1, 2 & 3 3SK34, 35, 36 & 37
Not Used
SBC Breakout Panel ISA 1
Parallel Printer 3SK06 (25 Way D Type)
NOTE
* denotes low active.
COM 2 3PL39 (9 Way D Type)
Not Used
Pin No. Signal Pin No. Signal
1 Keyboard Data 4 +5Volts (Fused)
2 Not Used 5 Keyboard Clock
3 Ground 6 Not Used
Pin No. Signal Pin No. Signal
1 +ve Transmit 5 Not Used
2 -ve Transmit 6 -ve Receive
3 +ve Receive 7 Not Used
4 Not Used 8 Not Used
Pin No. Signal Pin No. Signal
1 Strobe* 14 Auto Feed*
2 Data Bit 0 15 ERROR*
3 Data Bit1 16 INIT*
4 Data Bit 2 17 SLCT IN*
5 Data Bit 3 18 GND
6 Data Bit 4 19 GND
7 Data Bit 5 20 GND
8 Data Bit 6 21 GND
9 Data Bit 7 22 GND
10 ACK* 23 GND
11 BUSY 24 GND
12 PE (Paper End) 25 GND
13 SLCT
MACHINE PC
REAR PANEL CONNECTOR FUNCTIONS
Chapter Issue 1 Sep 02 Technical Reference Manual 5.19
Vision PC Adaptor Card ISA 5
Camera Lighting 3SK10 (9 Way D Type)
Camera Power and Trigger 3PL11 (9 Way D Type))
3SK40 (9 Way D Type)
Not Used
Vision Card PCI 3
Camera 0 3SK08 (15 Way Condensed D Type)
Camera 1 3SK09 (15 Way Condensed D Type)
Not Used.
Pin No. Signal Pin No. Signal
1 Ground 6 0V
2Rx 70V
3Tx 8 24 V US
4 Strobe 9 24V US
5Not Used
Pin No. Signal Pin No. Signal
1Not Used 60V
2 Not Used 7 Not Used
3 Not Used 8 +12 V Trig
4! Trig 9 24V US
5Not Used
Pin No. Signal Pin No. Signal
1 Not Used 9 +12V dc (Camera)
2 Video Input 10 Camera GND
3Not Used 11Shield
4 +12V dc (Camera) 12 Horizontal Drive GND (O/P)
5 Camera GND 13 Horizontal Drive Signal (O/P)
6 Not Used 14 Vertical Drive Signal (O/P)
7 Video GND 15 Vertical Drive GND (O/P)
8Not Used
