2 CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
2.13 Stencil Change Mechanism
MAINTENANCE MANUAL MICRON 11/2017 69
2.13 STENCIL CHANGE MECHANISM
1
2
3
4
Fig.13: View on Stencil Change Mechanism and Drip Tray
Item Description Item Description
1 Auto Drip Tray Actuator Piston 3 Stencil at Stop Sensor
2 Auto Drip Tray 4 Stencil Stop Actuator Arm Lever
2 CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
2.14 Squeegee Mechanism
70 MAINTENANCE MANUAL MICRON 11/2017
2.14 SQUEEGEE MECHANISM
1
2
3
4
5
Fig.14: View on Squeegee Mechanism
Item Description Item Description
1 Leadscrew (rear squeegee leadscrew
not shown)
4 Grease Nipples
2 Supernut (rear squeegee supernut not
shown)
5 Drive Belts
3 Spindle Shafts 6
2 CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
2.15 ProFlow
MAINTENANCE MANUAL MICRON 11/2017 71
2.15 PROFLOW
3
1
2
Fig.15: View on ProFlow Mount
Item Description Item Description
1 Leadscrew 3 Drive Belt
2 Linear Bearing Guide
