Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 341 221AA020 ROHS_HEX-SCT 8 1090006133-041 342 221HA004 WASHER 10 1090006133-042 343 221HA104 WASHER 8 1090006133-043 371 221AA018 ROHS_HEX-SCT 2 1090006133-071 374 221HA3…
Fig. D1-4
基板検出部
PEC Detection Section
Key No.12
See Fig.D1-1
C
C
A
A
3A1
3A1
383
396
389
384
391
396
3A1
3A1
391
389
395
394
393
384
390
396
396
391
384
389
389
384
391
390
3A3
371
343
374
371
343
374
398
399
3A0
398
399
3A0
341
342
343
398
399
3A0
3A4
3A4
3A3
381
392
381
385
398
399
3A0
398
399
3A0
386
381
3A3
388
3A4
3A4
381
3A3
385
1102-003
Fig. D1
基板認識部
PEC RECOGNITION SECTION
UNIT-3
Fig. D1
PEC RECG
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
341 221AA020 ROHS_HEX-SCT 8 1090006133-041
342 221HA004 WASHER 10 1090006133-042
343 221HA104 WASHER 8 1090006133-043
371 221AA018 ROHS_HEX-SCT 2 1090006133-071
374 221HA302 ROHS_WASHER 2 1090006133-074
381 222D0309 BEARING_RADIAL 4 209000610K-001
383 211DD858 PLATE 1 209000610K-003
384 216S3213 LEVER 4 209000610K-004
385 211FD393 BRACKET 2 209000610K-005
386 0900G12B PLATE 1 209000610K-006
388 211FD392 BRACKET 1 209000610K-008
389 221E0450 BOLT 4 209000610K-009
390 0900G12N SHAFT 2 209000610K-010
391 0900G125 SPRING_TENSION 4 209000610K-011
392 211FD391 BRACKET 1 209000610K-012
393 0900G12X BLOCK 1 209000610K-013
394 222D0211 BEARING_RADIAL 1 209000610K-014
395 216E1756 PIN_LOCATE 1 209000610K-015
396 222J0203 BUSH_BALL 4 209000610K-016
398 221AA016 ROHS_HEX-SCT 9 209000610K-018
399 221HA004 WASHER 9 209000610K-019
3A0 221HA104 WASHER 9 209000610K-020
3A1 221FA007 NUT_HEX 4 209000610K-021
3A3 221AA010 ROHS_HEX-SCT 4 209000610K-023
3A4 221FA005 NUT_HEX 4 209000610K-024
Fig. D1
1102-003
Fig. D1-4
UNIT-3
Fig. D1
PEC RECG
SIGMA-P4
Fig. D1-5
Y
軸駆動部
Y Axis Driving Section
405
401
404
408
407
402
403
406
See Fig. A-1
Key No. 34
0912-002
Fig. D1
基板認識部
PEC RECOGNITION SECTION
UNIT-3
Fig. D1
PEC RECG
