Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE Fig. B1-8R 0912-002 Fig. B1 753 221AA007 ROHS_HEX-SCT 1 3090004009-013 754 221HA301 ROHS_WASHER 1 3090004009-014 755 221CA005 SET_SCREW 2 3090004009-015 756 221F A009 NUT_…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. B1
1102-003
Fig. B1-8R
701 0900E01B SLIDE_BLOCK_A 1 109000402Y-001
702 0900E01C SLIDE_BLOCK_B 1 109000402Y-002
703 0900E01E COVER 2 109000402Y-003
704 0900E04K SIDE_PLATE_A 1 109000402Y-004
705 0900E04L SIDE_PLATE_B 1 109000402Y-005
706 0900E01K NUT_PLATE 2 109000402Y-006
707 0900E01W SENSOR_DOG 1 109000402Y-007
708 0900E01X SENSOR_PLATE 1 109000402Y-008
709 0900E01Q JOINT 2 109000402Y-009
710 0900E03V PLATE 1 109000402Y-010
711 0900E01N PLATE 1 109000402Y-011
712 0900E01P BASE_PLATE 1 109000402Y-012
713 0900E04Z COVER 1 109000402Y-013
714 0900E050 COVER 1 109000402Y-014
716 0900E032 CYLINDER 2 109000402Y-016
717 225F0253 PIPE_FITTINGS 4 109000402Y-017
718 0900E033 LINEAR_WAY 2 109000402Y-018
719 223Q0663 PULLEY_TIMING 2 109000402Y-019
720 223M0059 PULLEY_FLAT 3 109000402Y-020
721 0900E035 PHOTO_SENSOR 1 109000402Y-021
722 225F0360 PIPE_FITTINGS 2 109000402Y-022
723 213E0213 BOSS 2 109000402Y-023
724 0900E034 BOLT 8 109000402Y-024
725 221AA004 ROHS_HEX-SCT 8 109000402Y-025
726 221AA006 ROHS_HEX-SCT 12 109000402Y-026
727 221AA009 ROHS_HEX-SCT 9 109000402Y-027
728 221AA011 ROHS_HEX-SCT 4 109000402Y-028
729 221DA011 MACHINE_SCREW 2 109000402Y-029
730 221HA003 WASHER 16 109000402Y-030
731 221HA103 WASHER 16 109000402Y-031
732 221DA220 RO_MACHIN_SCREW 3 109000402Y-032
733 221FA010 NUT_HEX 3 109000402Y-033
734 0900E01U SLIDE_STAY 1 109000402Y-034
735 0900E01V SLIDE_STAY 1 109000402Y-035
736 221AA018 ROHS_HEX-SCT 4 109000402Y-036
737 221HA005 WASHER 3 109000402Y-037
744 223M0059 PULLEY_FLAT 1 3090004009-004
745 223Q0749 PULLEY_TIMING 1 3090004009-005
746 09004039 ASSY_MOTOR 1 3090004009-006
747 223Q0663 PULLEY_TIMING 1 3090004009-007
748 0900E01R BRACKET 1 3090004009-008
749 221H0274 WASHER 1 3090004009-009
750 221AA006 ROHS_HEX-SCT 1 3090004009-010
751 221HA003 WASHER 1 3090004009-011
752 221HA103 WASHER 2 3090004009-012
UNIT-1
Fig. B1
TABLE
SIGMA-P4
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. B1-8R
0912-002
Fig. B1
753 221AA007 ROHS_HEX-SCT 1 3090004009-013
754 221HA301 ROHS_WASHER 1 3090004009-014
755 221CA005 SET_SCREW 2 3090004009-015
756 221FA009 NUT_HEX 1 3090004009-016
757 221HA005 WASHER 1 3090004009-017
758 221HA105 WASHER 1 3090004009-018
761 0900E044 TUBE_D4 1 409000403R-001
UNIT-1
Fig. B1
TABLE
SIGMA-P4
MEMO
