2-7
2
asic operation
n
Feeder
-related errors
Code Error name and description
Ea03952
Feeder Pitch is not set to the following parts data.
State Feeder Pitch is not set to the following parts data.
Cause Feeder Pitch is not set to the following parts data.
Action Check the parts data and set correct Feeder pitch.
Ea30100
Feed Not Completed
State Feeder could not finish feeding parts when the head reaches parts.
Cause
Feed timer setting is too short compared to the possible feed time, or it took time to drive the feeder due to an
accidental cause.
Action Please confirm whether never to hinder the feeding operation.
Ea30101
Feeder does not Exist.
State The feeder cannot be detected. Please confirm the set position of feeder.
Cause The feeder cannot be detected. Please confirm the set position of feeder.
Action
Please comfirm the feeder set.
If feeder is attached but this error occurred. Please check the feeder status on [UNIT]-[FEEDER] screen.
If feeder exist but data is not correctly read,
Push the [RELOAD] button on [Unit]-[Feeder] screen, then confirm the feeder data is correctly read, or clear
this error and wait for 10 seconds then restart the machine.
Ea30102
Feeder Error State
State Because the error occurs by the feeder, the feeding operation cannot be executed.
Cause Because the error occurs by the feeder, the feeding operation cannot be executed.
Action
Please confirm the state of the feeder.
Please remove the cause of the error, and set the feeder again once.
Ea30106
Feeder Control Board detection error.
State Feeder control board could not be detected.
Cause Feeder control board could not be detected.
Action
Please confirm the state of electric contact of the feeder cart.
The feeder cart state can be confirmed from feeder cart LED.
When this error occurs repeatedly, the breakdown of the feeder cart board is thought.
2-8
2
asic operation
n
Others
Code Error name and description
Ea00109
EMERGENCY STOP FUNCTION DURING MOUNT
State
EMERGENCY STOP FUNCTION is executed duringmounting sequense. So, there is danger that
mountsequense finished under the unusual condition. Can it stop automatically after it installs it when an
automatic driving is restarted, and the image at the installation position be confirmed.
Cause Emergency stop was triggered during component placement.
Action Use "trace" to check whether the component is placed at the specified point.
Ea00818
QUICK STOP ACTIVE
State QUICK STOP FUNCTION is now active.
Cause Emergency stop was triggered by the "conveyor width safety check sensor".
Action Check the status of the conveyor width safety check sensor.
Ea02722
DON'T YOU NEED HALFWAY CONTINUE?
State
A board that is not finished to mount exist on the mounting position. If you continue auto running, a halfway
board may be transferred. Please confirm the board condition and execute halfway continue command if
necessary.
Cause
A board for which component mounting is not completed is left in the component placement position. If
automatic operation continues as is, then the unfinished board may be transferred downstream.
Action
Check the board in the component placement position. When it is not finished, run "Halfway Continue"
command to resume component mounting on that board.
Ea02889
EMERGENCY STOP FUNCTION DURING PICK
State
EMERGENCY STOP FUNCTION is executed during picking sequence. There is a chance that the picking
sequence finished under suspicious conditions. Please check condition of the component.
Cause
Emergency stop was triggered during component pickup. Component pickup operation might have been
unstable.
Action Check how the component is being picked up.
Ea07871
CAN NOT EXECUTE COMMAND
State
Can not execute this command , because RESET is not finished completely. Please try the RESET command
again, and finish it.
Cause Unable to run commands since reset is not complete.
Action Perform a reset again.
Ea01277
X1 Axis 2nd LIMIT OVER
State Move the axis until error message disappears. The "EMERGENCY STOP" light will go off.
Cause X1-axis secondary limit was exceeded.
Action Move the X1 axis by hand to a safe position.
Ea01278
Y1 Axis 2nd LIMIT OVER
State Move the axis until error message disappears. The "EMERGENCY STOP" light will go off.
Cause Y1-axis secondary limit was exceeded.
Action Move the Y1 axis by hand to a safe position.
Ea29920
FEEDER CART(FRONT1) IS NOT SET
State Emergency stop function is activated.
Cause Feeder cart (front 1) is not set.
Action
Set the Feeder Cart or close the Cart Cover, and press the READY button to re-enable the machine.
The "EMERGENCY STOP" light will go off.
Ea29921
FEEDER CART(FRONT2) IS NOT SET
State Emergency stop function is activated.
Cause Feeder cart (front 2) is not set.
Action
Set the Feeder Cart or close the Cart Cover, and press the READY button to re-enable the machine.
The "EMERGENCY STOP" light will go off.
2-9
2
asic operation
Code Error name and description
Ea29922
FEEDER CART(REAR1) IS NOT SET
State Emergency stop function is activated.
Cause Feeder cart (rear 1) is not set.
Action
Set the Feeder Cart or close the Cart Cover, and press the READY button to re-enable the machine.
The "EMERGENCY STOP" light will go off.
Ea29923
FEEDER CART(REAR2) IS NOT SET
State Emergency stop function is activated.
Cause Feeder cart (rear 2) is not set.
Action
Set the Feeder Cart or close the Cart Cover, and press the READY button to re-enable the machine.
The "EMERGENCY STOP" light will go off.
