1-E 本 体部 :DSP M ain Bo dy :DSP パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 1009 859 8AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S13 ( KN610098598AA-10-5 )
Ref
No.
Remarks
R
1
Q'ty
1-D
本
体部
:DSP
Main Body:DSP
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610098598AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BASE
1
1 N210117005AA
BRACKET
1
2 N210117764AC
BRACKET
1
3 KXFB00JJA01
BLOWER
1
4 N610107640AA
BOLT
2
5 N510017552AA
SSS 003 Hexagon socket button head screw M5X6-10.9 A2J (Trivalent)
FAN-GUARD
2
6 KXF07S8AA00 109-619E
SPACER
3
7 N510017103AA CB-504E
WASHER
3
8 N210117345AA
WASHER
4
9 N210117344AA
BAND
12
10 N510028769AA AS-50
Vacuum Pump Cooling Fan
2
11 N610069822AA
FAN-GUARD
2
12 KXFP007AA00 109-620
BRACKET
1
13 N210132707AA
BRACKET
1
14 N210120763AB
S12
--
( KN610098598AA-10-4 )
1-E
本
体部
:DSP
Main Body:DSP
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610098598AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S13
( KN610098598AA-10-5 )
Ref
No.
Remarks
R
1
Q'ty
1-E
本
体部
:DSP
Main Body:DSP
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610098598AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BLOCK
2
1 N210120035AA
PLATE
2
2 N210120037AB
BLOCK
2
3 N210122859AB
BRACKET
1
4 N210122484AC
PLATE
1
5 N210120990AB
COVER
1
6 N210129456AA
PLATE
1
7 N210117094AA
PLATE
1
8 N210119196AA
COVER
1
9 N210129457AA
PLATE
1
10 N210122472AA
RUBBER-LEG
4
11 KXF01E6AA00 C-30-RK-12
SPACER
2
13 N510037861AA ASF-5100E
FILTER
1
14 N510016407AA AFM20-02BC-R-X2106
NIPPLE
1
15 N510021600AA VRN-0302
JOINT
1
16 N510019579AA (L)3/8
HOSE
1
17 N510002541AA OUA8X12-5M-03B
VALVE
1
18 N510038394AA VP344-2DZ-02A
JOINT
2
19 KXF0DWRNA00 KQ2L12-02S
SILENCER
1
20 KXF00WEAA00 AN203-02
JOINT
1
21 KXF0E108A00 KQ2U12-99
SWITCH
1
22 N510050112AA ISE30A-C4L-N-MB
BOLT
6
23 N510022475AA SRBS-M3X6
REGULATOR
1
24 N510016394AA AR20-02-X2232-A
REGULATOR
1
25 N510016408AA IR2010-02-DIJ00454
SPACER
3
26 N510038219AA ASF-660E
SCREW
3
27 XXE6D20FT
Hexagon socket set screw Cup point M6X20-45H SOB
SPACER
2
28 N510037912AA ASF-5140E
SPACER
2
29 N510029484AA ASF-4110E
JOINT
1
30 KXF0DZH3A00 KQ2R06-12
BOTTLE
1
31 KXF07M8AA00 5-010-03
COVER
1
41 N210129458AA
JOINT
1
42 KXF09QCAA00 KQ2P-04
JOINT
1
43 KXF09ZVAA00 KQ2R04-06
JOINT
1
44 KXF0E109A00 KQ2T12-00
JOINT
1
45 KXF0E36NA00 KQ2R08-12
S14
--
( KN610098598AA-10-5 )
