15 MODULARITY Mechanical 0 = Euro-ange B10 Electrical (output A + B) 0 = HCHTL + HTL (supply 9-30 V dc, output 3+6 channels) * 1 = HCHTL + TTL (supply 9-30 Vdc + 5 V dc, output 3+6 channels) * 2 = HTL + HTL (supply 9-30…
14
Flange
0 = Euro ange B10
Functionality
0 = Standard
1 = ADS Classic
2 = ADS Online (only with electronics
options 5, 6 or 7)
3 = Programmable overspeed (only available with connection option 4 or 5, and
electronics option 5, 6, or 7)
Shaft
9 = Ø11 mm solid shaft with key nut
Connection
1 = Connector M23, 12 pin CW
2 = Connector M23, 12 pin CCW
4 = Cable gland, M20 for Ø8-11 mm cables
5 = Cable gland, M20 for Ø11-14 mm cables
3 = Pre-mounted cable, 1.5 m
9 = Pre-mounted cable, xx m
Electronics
1 = TTL (supply 5 Vdc, output 5 Vdc)
5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
6 = HTL (supply 9-30 Vdc, output 9-30 Vdc)
7 = RS422 (supply 9-30 Vdc, output 5 Vdc)
9 = Sinusoidal 1 Vpp (supply 5 Vdc, output 1 Vpp)
Resolution
10, 50, 100, 150, 200, 256, 300, 360, 400, 500, 512, 600, 720, 800, 900, 1000, 1024, 1200, 1250, 1800, 2000, 2048, 2400, 2500,
3072, 4000, 4096, 4800, 5000, 6350, 10000 ppr
Sinusodial 1 Vpp: 1024, 2048 ppr
Other resolutions available upon request.
Code keys
8 5 0 - 0 9 6 -
850
15
MODULARITY
Mechanical
0 = Euro-ange B10
Electrical (output A + B)
0 = HCHTL + HTL (supply 9-30 Vdc, output 3+6 channels) *
1 = HCHTL + TTL (supply 9-30 Vdc + 5 Vdc, output 3+6 channels) *
2 = HTL + HTL (supply 9-30 Vdc, output 6+6 channels)
3 = TTL + TTL (supply 5 Vdc, output 6+6 channels)
4 = HTL + TTL (supply 9-30 + 5 Vdc, output 6+6 channels)
5 = HTL + RS422 (supply 9-30 Vdc, output 6+6 channels)
6 = HCHTL + HCHTL (supply 9-30 Vdc, output 6+6 channels) */**
7 = RS422 + RS422 (supply 9-30 Vdc, output 6+6 channels)
* Variants with HCHTL are only available with pre-mounted cable
or connector (connection option 1, 2, 3 or 9)
** Only available with 2 x equal pulserate (plastic or glass)
Shaft
9 = Ø 11 mm solid shaft with key nut
Connection
1 = 2 x Connector, radial 12 pin M23 CW
2 = 2 x Connector, radial 12 pin M23 CCW
4 = 2 x M20 cable gland, for cable Ø8-11 mm
5 = 2 x M20 cable gland, for cable Ø11-14 mm
3 = 2 x Cable (PVC), radial 1,5 m
9 = 2 x Cable (PVC), radial free length xx m
Code disc
0 = Check the list below to see which pulse rates are avalable.
Pulse rates
2 x equal pulse rate
500, 600, 1000, 1024, 2000, 2048, 2500, 3072, 4096, 5000, 6000, 6350, 8192, 10000, 1500, 50, 60, 400, 600, 750, 900, 1200,
1250, 1800, 3000, 3750, 4000
Odd pulse rate
1024-500, 1024-600, 1024-2000, 1024-2048, 1024-4096, 1024-6350, 1024-10000, 2048-6000, 2048-8192, 100-2048,
24-2048, 1024-15, 1024-50, 5000-1024, 5000-2048, 500-360, 1024-150, 1024-30, 1024-300, 1024-512, 2048-150, 2048-2,
2048-200, 2048-300, 2048-500, 2048-512, 4096-2048, 2048-500, 5000-300, 2048-2500
855 Duo
8 5 5 - 0 9 9 0 - -
A
B
16
8 0 1 - -
Shaft
2 = Hollow shaft 12 mm with insulation up to 2,5 kV
6 = Hollow shaft 12 mm with keyway with insulation up to 2,5 kV
7 = Hollow shaft 16 mm with insulation up to 2,5 kV
0 = Hollow shaft 17 mm taper with insulation up to 2,5 kV
Flange
1 = Torque bracket 120°
2 = Torque bracket 315°
Output
1 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
2 = HTL (supply 9-30 Vdc, output 9-30 Vdc)
5 = RS422 (supply 9-30 Vdc, output 5 Vdc)
7 = TTL (supply 5 Vdc, output 5 Vdc)
9 = 1 Vpp (supply 9-30 Vdc)
0 = 1 Vpp (supply 5 Vdc)
Connection
1 = M20 cable gland 8-11mm (not for model with Optolink)
2 = Pre-mounted cable xx m (not for model with Optolink)
4 = M23 connector 12 pin
Connection direction
1 = Radial
2 = Adjustable (not for models with Optolink)
Functionality
1 = Standard
2 = Overvoltage protected
3 = ADS Classic (not available with 1 Vpp)
4 = ADS Classic overvoltage protected (not available with 1 Vpp)
5 = ADS Online (not available with TTL or 1 Vpp)
6 = ADS Online overvoltage protected (not available with TTL or 1 Vpp)
7 = Optolink
8 = Optolink overvoltage protected
Resolution
500, 1000, 1024, 2048, 2500, 3072, 4096, 5000, 8192, 10000 ppr
1 Vpp: 1024, 2048 ppr
Other resolutions available upon request.
801
