17 MODULARITY 8 0 3 - - Shaft 2 = Hollow shaft 12 mm with insulation 7 = Hollow shaft 16 mm with insulation 8 = Through-going hollow shaft 25 mm with insulation 9 = Through-going hollow shaft 1 inch with insulation Flang…
16
8 0 1 - -
Shaft
2 = Hollow shaft 12 mm with insulation up to 2,5 kV
6 = Hollow shaft 12 mm with keyway with insulation up to 2,5 kV
7 = Hollow shaft 16 mm with insulation up to 2,5 kV
0 = Hollow shaft 17 mm taper with insulation up to 2,5 kV
Flange
1 = Torque bracket 120°
2 = Torque bracket 315°
Output
1 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
2 = HTL (supply 9-30 Vdc, output 9-30 Vdc)
5 = RS422 (supply 9-30 Vdc, output 5 Vdc)
7 = TTL (supply 5 Vdc, output 5 Vdc)
9 = 1 Vpp (supply 9-30 Vdc)
0 = 1 Vpp (supply 5 Vdc)
Connection
1 = M20 cable gland 8-11mm (not for model with Optolink)
2 = Pre-mounted cable xx m (not for model with Optolink)
4 = M23 connector 12 pin
Connection direction
1 = Radial
2 = Adjustable (not for models with Optolink)
Functionality
1 = Standard
2 = Overvoltage protected
3 = ADS Classic (not available with 1 Vpp)
4 = ADS Classic overvoltage protected (not available with 1 Vpp)
5 = ADS Online (not available with TTL or 1 Vpp)
6 = ADS Online overvoltage protected (not available with TTL or 1 Vpp)
7 = Optolink
8 = Optolink overvoltage protected
Resolution
500, 1000, 1024, 2048, 2500, 3072, 4096, 5000, 8192, 10000 ppr
1 Vpp: 1024, 2048 ppr
Other resolutions available upon request.
801
17
MODULARITY
8 0 3 - -
Shaft
2 = Hollow shaft 12 mm with insulation
7 = Hollow shaft 16 mm with insulation
8 = Through-going hollow shaft 25 mm with insulation
9 = Through-going hollow shaft 1 inch with insulation
Flange
1 = Torque bracket 120°
2 = Torque bracket 315°
Output
1 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
2 = HTL (supply 9-30 Vdc, output 9-30 Vdc)
5 = RS422 (supply 9-30 Vdc, output 5 Vdc)
7 = TTL (supply 5 Vdc, output 5 Vdc)
9 = 1 Vpp (supply 9-30 Vdc)
0 = 1 Vpp (supply 5 Vdc)
Connection
1 = M20 cable gland 8-11mm (not for model with Optolink)
2 = Pre-mounted cable xx m (not for model with Optolink)
4 = M23 connector 12 pin
Connection direction
1 = Radial
2 = Adjustable (not for models with Optolink)
Functionality
1 = Standard
2 = Overvoltage protected
3 = ADS Classic (not available with 1Vpp)
4 = ADS Classic overvoltage protected (not available with 1 Vpp)
5 = ADS Online (not available with TTL or 1Vpp)
6 = ADS Online overvoltage protected (not available with TTL or 1 Vpp)
7 = Optolink
8 = Optolink overvoltage protected
Resolution
500, 1000, 1024, 2048, 2500, 3072, 4096, 5000, 8192, 10000 ppr
1 Vpp: 1024, 2048 ppr
Other resolutions available upon request.
803
18
8 6 1 - -
Flange
0 = Standard
1 = Torque bracket 120°
Functionality
0 = Standard
1 = ADS Classic
2 = ADS Online (only with electronics options 5, 6, or 7)
3 = Programmable overspeed (only available with connection option 4 or 5, electronics option
5, 6, or 7, and 6 channels)
Shaft
7 = Ø12 mm hollow shaft with insulation
8 = Ø16 mm hollow shaft with insulation
Connection
1 = Connector M23, 12 pin CW
2 = Connector M23, 12 pin CCW
4 = Cable gland, M20 for Ø8-11 mm cables
5 = Cable gland, M20 for Ø11-14 mm cables
3 = Pre-mounted cable, 1.5 m
9 = Pre-mounted cable, xx m
Electronics
1 = TTL (supply 5 Vdc, output 5 Vdc)
5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
6 = HTL (supply 9-30 Vdc, output 9-30 Vdc)
7 = RS422 (supply 9-30 Vdc, output 5 Vdc)
9 = Sinusoidal 1 Vpp (supply 5 Vdc, output 1 Vpp)
Number of channels
5 = 3 channels (only for HCHTL)
6 = 6 channels
Resolution
10, 50, 100, 150, 200, 256, 300, 360, 400, 500, 512, 600, 720, 800, 900, 1000, 1024, 1200, 1250, 1800, 2000, 2048, 2400, 2500,
3072, 4000, 4096, 4800, 5000, 6350, 10000 ppr
Sinusodial 1 Vpp: 1024, 2048 ppr
Other resolutions available upon request.
861
