19 MODULARITY 8 6 2 - 0 - Flange 0 = Standard 1 = T orque bracket 120° 2 = T orque bracket 330° Shaft 7 = Ø12 mm hollow shaft with insulation up to 2.5 kV 8 = Ø16 mm hollow shaft with insulation up to 2.5 kV 9 = Ø17 mm t…

8 6 1 - -

Flange

0 = Standard

1 = Torque bracket 120°

Functionality

0 = Standard

1 = ADS Classic

2 = ADS Online (only with electronics options 5, 6, or 7)

3 = Programmable overspeed (only available with connection option 4 or 5, electronics option

5, 6, or 7, and 6 channels)

Shaft

7 = Ø12 mm hollow shaft with insulation

8 = Ø16 mm hollow shaft with insulation

Connection

1 = Connector M23, 12 pin CW

2 = Connector M23, 12 pin CCW

4 = Cable gland, M20 for Ø8-11 mm cables

5 = Cable gland, M20 for Ø11-14 mm cables

3 = Pre-mounted cable, 1.5 m

9 = Pre-mounted cable, xx m

Electronics

1 = TTL (supply 5 Vdc, output 5 Vdc)

5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)

6 = HTL (supply 9-30 Vdc, output 9-30 Vdc)

7 = RS422 (supply 9-30 Vdc, output 5 Vdc)

9 = Sinusoidal 1 Vpp (supply 5 Vdc, output 1 Vpp)

Number of channels

5 = 3 channels (only for HCHTL)

6 = 6 channels

Resolution

10, 50, 100, 150, 200, 256, 300, 360, 400, 500, 512, 600, 720, 800, 900, 1000, 1024, 1200, 1250, 1800, 2000, 2048, 2400, 2500,

3072, 4000, 4096, 4800, 5000, 6350, 10000 ppr

Sinusodial 1 Vpp: 1024, 2048 ppr

Other resolutions available upon request.

861

MODULARITY

8 6 2 - 0 -

Flange

0 = Standard

1 = Torque bracket 120°

2 = Torque bracket 330°

Shaft

7 = Ø12 mm hollow shaft with insulation up to 2.5 kV

8 = Ø16 mm hollow shaft with insulation up to 2.5 kV

9 = Ø17 mm taper hollow shaft with insulation up to 2.5 kV

Connection

1 = Connector M23, 12 pin CW

2 = Connector M23, 12 pin CCW

4 = Cable gland, M20 for Ø8-11 mm cables

5 = Cable gland, M20 for Ø11-14 mm cables

3 = Pre-mounted cable, 1.5 m

9 = Pre-mounted cable, xx m

Electronics

1 = TTL (supply 5 Vdc, output 5 Vdc)

2 = Overvoltage protected HCHTL (supply 9-30 Vdc, output 9-30 Vdc)

3 = Overvoltage protected HTL (supply 9-30 Vdc, output 9-30 Vdc)

5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)

6 = HTL (supply 9-30 Vdc, output 9-30 Vdc)

7 = RS422 (supply 9-30 Vdc, output 5 Vdc)

9 = Sinusoidal 1 Vpp (supply 5 Vdc, output 1 Vpp)

Functionality

4 = Standard, output with 3 channels (only for HCHTL)

5 = ADS Classic, output with 3 channels (only for HCHTL)

6 = Standard, output with 6 channels

7 = ADS Classic, output with 6 channels

8 = 3 channels with ADS Online (only for electronics option 5)

9 = 6 channels with ADS Online (only for electronics option 5, 6, and 7)

1 = 6 channels programmable overspeed (only available with connection option 4 or 5, and electronics option 5, 6, and 7)

Resolution

10, 50, 100, 150, 200, 256, 300, 360, 400, 500, 512, 600, 720, 800, 900, 1000, 1024, 1200, 1250, 1800, 2000, 2048, 2400, 2500,

3072, 4000, 4096, 4800, 5000, 6350, 10000 ppr

Sinusodial 1 Vpp: 1024, 2048 ppr

Other resolutions available upon request.

862

8 6 5 - 9 0 - -

Mechanical

0 = Standard

1 = Torque bracket 135°

Electrical (output A + B)

0 = HCHTL + HTL (supply 9-30 Vdc, output 3+6 channels) *

1 = HCHTL + TTL (supply 9-30 Vdc + 5 Vdc, output 3+6 channels) *

2 = HTL + HTL (supply 9-30 Vdc, output 6+6 channels)

3 = TTL + TTL (supply 5 Vdc, output 6+6 channels)

4 = HTL + TTL (supply 9-30 + 5 Vdc, output 6+6 channels)

5 = HTL + RS422 (supply 9-30 Vdc, output 6+6 channels)

6 = HCHTL + HCHTL (supply 9-30 Vdc, output 6+6 channels) */**

7 = RS422 + RS422 (supply 9-30 Vdc, output 6+6 channels)

* Variants with HCHTL are only available with pre-mounted cable or connector

(connection option 1, 2, 3 or 9)

** Only available with 2 x equal pulserate (plastic or glass)

Shaft

4 = Ø 12 mm, Insulated, Ceramic bearings

5 = Ø 16 mm, Insulated, Ceramic bearings

6 = Ø 17 mm taper shaft, Insulated, Ceramic bearings

7 = Ø 12 mm, bushing Insulated, steel bearings

8 = Ø 16 mm, bushing insulated, steel bearings

Connection

1 = 2 x Connector, radial 12 pin M23 CW

2 = 2 x Connector, radial 12 pin M23 CCW

4 = 2 x M20 cable gland, for cable Ø8-11 mm

5 = 2 x M20 cable gland, for cable Ø11-14 mm

3 = 2 x Cable (PVC), radial 1,5 m

9 = 2 x Cable (PVC), radial free length xx m

Code disc

0 = Check the list below to see which pulse rates are avalable.

Pulse rates

2 x equal pulse rate

500, 600, 1000, 1024, 2000, 2048, 2500, 3072, 4096, 5000, 6000, 6350, 8192, 10000, 1500, 50, 60, 400, 600, 750, 900, 1200,

1250, 1800, 3000, 3750, 4000

Odd pulse rate

1024-500, 1024-600, 1024-2000, 1024-2048, 1024-4096, 1024-6350, 1024-10000, 2048-6000, 2048-8192, 100-2048,

24-2048, 1024-15, 1024-50, 5000-1024, 5000-2048, 500-360, 1024-150, 1024-30, 1024-300, 1024-512, 2048-150, ’2048-2,

2048-200, 2048-300, 2048-500, 2048-512, 4096-2048, 2048-500, 5000-300, 2048-2500

865 Duo
