22 Flange 0 = Euro ange B10 Shaft 9 = Ø11 mm solid shaft with key nut Connection 1 = Connector M23, 12 pin CW 2 = Connector M23, 12 pin CCW 4 = Cable gland M20 for Ø8-11 mm cables 5 = Cable gland M20 for Ø11-14 mm cable…
21
MODULARITY
8 4 1 - -
Ex classes
0 = Tamb= -40ºC..+40ºC, RPMmax = 4200 (T6)
1 = Tamb= -40ºC..+60ºC, RPMmax = 4200 (T5)
2 = Tamb= -40ºC..+70ºC, RPMmax = 1500 (T5)
3 = Tamb= -40ºC..+70ºC, RPMmax = 6000 (T4)
Flange
0 = Standard
1 = Torque bracket 120°
Shaft
12 = Ø12 mm hollow shaft
16 = Ø16 mm hollow shaft
Electronics
5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
Functionality
4 = Standard, output with 3 channels
5 = Standard, output with 6 channels
6 = ADS Classic, output with 6 channels
Resolution
XXXXX ppr
Accessories for Ex use Part number
Ex-rated cable gland
Cable
Torque arm M6
1113061-01
1322311-xx
1254632-xx
841, Ex
22
Flange
0 = Euro ange B10
Shaft
9 = Ø11 mm solid shaft with key nut
Connection
1 = Connector M23, 12 pin CW
2 = Connector M23, 12 pin CCW
4 = Cable gland M20 for Ø8-11 mm cables
5 = Cable gland M20 for Ø11-14 mm cables
9 = Pre-mounted cable XX m
Electronics
5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
Number of channels
6 = 6 channels
Resolution
1024, 2048 ppr
Other resolutions between 500-5000 ppr on request.
FSI 8 5 0 5 6 0 -
850, FSI
23
MODULARITY
Flange
0 = Standard
1 = Torque bracket 120°
2 = Torque bracket 330°
Shaft
7 = Ø12 mm blind hollow shaft with key way
8 = Ø16 mm blind hollow shaft with key
Connection
1 = Connector M23, 12 pin CW
2 = Connector M23, 12 pin CCW
4 = Cable gland M20 for Ø8-11 mm cables
5 = Cable gland M20 for Ø11-14 mm cables
9 = Pre-mounted cable XX m
Electronics
5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
Number of channels
6 = 6 channels
Resolution
1024, 2048 ppr
Other resolutions between 500-5000 ppr available upon request.
FSI 8 6 2 5 6 0 -
862, FSI
