21 MODULARITY 8 4 1 - - Ex classes 0 = T amb= -40ºC..+40ºC, RPMmax = 4200 (T6) 1 = T amb= -40ºC..+60ºC, RPMmax = 4200 (T5) 2 = T amb= -40ºC..+70ºC, RPMmax = 1500 (T5) 3 = T amb= -40ºC..+70ºC, RPMmax = 6000 (T4) Flange 0 …
20
8 6 5 - 9 0 - -
Mechanical
0 = Standard
1 = Torque bracket 135°
Electrical (output A + B)
0 = HCHTL + HTL (supply 9-30 Vdc, output 3+6 channels) *
1 = HCHTL + TTL (supply 9-30 Vdc + 5 Vdc, output 3+6 channels) *
2 = HTL + HTL (supply 9-30 Vdc, output 6+6 channels)
3 = TTL + TTL (supply 5 Vdc, output 6+6 channels)
4 = HTL + TTL (supply 9-30 + 5 Vdc, output 6+6 channels)
5 = HTL + RS422 (supply 9-30 Vdc, output 6+6 channels)
6 = HCHTL + HCHTL (supply 9-30 Vdc, output 6+6 channels) */**
7 = RS422 + RS422 (supply 9-30 Vdc, output 6+6 channels)
* Variants with HCHTL are only available with pre-mounted cable or connector
(connection option 1, 2, 3 or 9)
** Only available with 2 x equal pulserate (plastic or glass)
Shaft
4 = Ø 12 mm, Insulated, Ceramic bearings
5 = Ø 16 mm, Insulated, Ceramic bearings
6 = Ø 17 mm taper shaft, Insulated, Ceramic bearings
7 = Ø 12 mm, bushing Insulated, steel bearings
8 = Ø 16 mm, bushing insulated, steel bearings
Connection
1 = 2 x Connector, radial 12 pin M23 CW
2 = 2 x Connector, radial 12 pin M23 CCW
4 = 2 x M20 cable gland, for cable Ø8-11 mm
5 = 2 x M20 cable gland, for cable Ø11-14 mm
3 = 2 x Cable (PVC), radial 1,5 m
9 = 2 x Cable (PVC), radial free length xx m
Code disc
0 = Check the list below to see which pulse rates are avalable.
Pulse rates
2 x equal pulse rate
500, 600, 1000, 1024, 2000, 2048, 2500, 3072, 4096, 5000, 6000, 6350, 8192, 10000, 1500, 50, 60, 400, 600, 750, 900, 1200,
1250, 1800, 3000, 3750, 4000
Odd pulse rate
1024-500, 1024-600, 1024-2000, 1024-2048, 1024-4096, 1024-6350, 1024-10000, 2048-6000, 2048-8192, 100-2048,
24-2048, 1024-15, 1024-50, 5000-1024, 5000-2048, 500-360, 1024-150, 1024-30, 1024-300, 1024-512, 2048-150, ’2048-2,
2048-200, 2048-300, 2048-500, 2048-512, 4096-2048, 2048-500, 5000-300, 2048-2500
865 Duo
A
B
21
MODULARITY
8 4 1 - -
Ex classes
0 = Tamb= -40ºC..+40ºC, RPMmax = 4200 (T6)
1 = Tamb= -40ºC..+60ºC, RPMmax = 4200 (T5)
2 = Tamb= -40ºC..+70ºC, RPMmax = 1500 (T5)
3 = Tamb= -40ºC..+70ºC, RPMmax = 6000 (T4)
Flange
0 = Standard
1 = Torque bracket 120°
Shaft
12 = Ø12 mm hollow shaft
16 = Ø16 mm hollow shaft
Electronics
5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
Functionality
4 = Standard, output with 3 channels
5 = Standard, output with 6 channels
6 = ADS Classic, output with 6 channels
Resolution
XXXXX ppr
Accessories for Ex use Part number
Ex-rated cable gland
Cable
Torque arm M6
1113061-01
1322311-xx
1254632-xx
841, Ex
22
Flange
0 = Euro ange B10
Shaft
9 = Ø11 mm solid shaft with key nut
Connection
1 = Connector M23, 12 pin CW
2 = Connector M23, 12 pin CCW
4 = Cable gland M20 for Ø8-11 mm cables
5 = Cable gland M20 for Ø11-14 mm cables
9 = Pre-mounted cable XX m
Electronics
5 = HCHTL (supply 9-30 Vdc, output 9-30 Vdc)
Number of channels
6 = 6 channels
Resolution
1024, 2048 ppr
Other resolutions between 500-5000 ppr on request.
FSI 8 5 0 5 6 0 -
850, FSI
