YC8-KLM-000_PartsList.pdf - 第17页

29 12 14 26 19 18 3 42 8 21 27 25 22 39 11 41 44 40 8 17 39 8 41 40 7 41 23 6 6 44 4 1 16 24 38 8 36 37 5 31 43 37 13 34 7 32 38 13 28 46 45 2 47 2 30 33 38 20 15 38 33 2 13 9 10 30 38 35 Z1-axis (for Right Head) Head Se…

20

5

18

3

4

8

21

27

11

8

6

13

12

7

1

25

25

1

24

19

16

15

2

22

26

9

10

14

23

19

17

Fiducial Camera

Head Section

KLM-1206

5-2

NO

Parts_No.

Parts_Name

Q_ty

Remarks

Compati

Revision_No._date

1

$NK-3N

NYLON CLIP

3

2

90562-13J120

SPACER

2

3

90990-01J020

BOLT HEX,SOCKET HEAD

4

4

KHN-M7600-00

FIDUCIAL LIGHT ASSY

1

5

91312-03014

BOLT HEX,SOCKET HEAD

4

6

KJX-M71H7-00

BRACKET,FID.LIGHT

1

7

KJX-M7210-00

CCD CAMERA

1

8

91312-03020

BOLT HEX,SOCKET HEAD

4

9

91312-04006

BOLT HEX,SOCKET HEAD

2

10

91312-04008

BOLT HEX,SOCKET HEAD

4

11

91312-04016

BOLT HEX,SOCKET HEAD

4

12

91312-04025

BOLT HEX,SOCKET HEAD

2

13

KJX-M7211-00

LENS FID.

1

14

KLD-M66N5-10

HNS,CZ-FLEX FID(2V)

1

15

KLD-M713R-00

SHEET,RUBBER

1

16

KLD-M7158-00

BRKT,HNS.SUB

1

17

KLD-M7161-00

BRKT, HNS 3

1

18

KLD-M7181-00

MULTI MACS

1

19

98902-03006

SCREW BINDING HEAD

4

20

KLD-M71H2-00

BRKT,CCD CAMERA

1

21

KLD-M71H3-00

HOLDER,CCD CAMERA

1

22

KLD-M71HB-00

BRKT. CABLE

1

23

KV7-M7165-00

SEAL DON'T TOUCH

1

24

97602-03306

SCREW PAN HEAD W/WASHER

2

25

97602-04306

SCREW PAN HEAD W/WASHER

3

26

99480-04008

PIN,PARALLEL

2

27

99480-04012

PIN,PARALLEL

4

29

12

14

26

19

18

3

42

8

21

27

25

22

39

11

41

44

40

8

17

39

8

41

40

7

41

23

6

6

44

4

1

16

24

38

8

36

37

5

31

43

37

13

34

7

32

38

13

28

46

45

2

47

2

30

33

38

20

15

38

33

2

13

9

10

30

38

35

Z1-axis (for Right Head)

Head Section

KLM-1206

5-3

NO

Parts_No.

Parts_Name

Q_ty

Remarks

Compati

Revision_No._date

1

$NK-3N

NYLON CLIP

1

2

90562-13J100

SPACER

4

3

90933-02J605

BEARING

1

4

90990-12J006

SCREW, BIN. HEAD W/W

1

5

90K24-034503

AC SERVO MOTOR ASSY

1

Z1-axis Drive for "Primary Right-side Head"

6

91312-03010

BOLT HEX,SOCKET HEAD

6

7

91312-03012

BOLT HEX,SOCKET HEAD

6

8

91312-03020

BOLT HEX,SOCKET HEAD

14

9

91312-04006

BOLT HEX,SOCKET HEAD

4

10

91312-04020

BOLT HEX,SOCKET HEAD

1

11

91312-05016

BOLT HEX,SOCKET HEAD

4

12

91312-05020

BOLT HEX,SOCKET HEAD

2

13

92012-04006

BOLT, BOTTON HEAD

8

14

92902-05200

WASHER,PLAIN

2

15

95302-04600

NUT HEXAGON

1

16

KHN-M712A-00

BEARING

1

17

KJX-M7106-10

DAMPER LOW

1

18

KJX-M711P-00

CIRCLIP 5

1

19

KJX-M712G-00

PLATE BRG.

1

20

KLD-M66N4-10

HNS,R-FLEX(2V-R1)

1

21

KLD-M7102-00

PLATE HEAD

1

22

KLD-M7103-00

LM GUIDE

1

23

KLD-M7106-00

DAMPER

1

24

KLD-M7110-00

HOLDER Z

1

25

KLD-M7112-00

HOLDER NUT

1

26

KLD-M711N-00

HOLDER BRG

1

27

KLD-M7121-00

BALL SCREW

1

28

KLD-M713P-20

SPRING RETURN

1

29

KLD-M7173-00

GUIDE,SPRING

1

30

KLD-M713R-00

SHEET,RUBBER

2

31

KLD-M7153-01

BRKT,SPRING Z

1

32

KLD-M7155-02

COVER,GEAR

1

33

KLD-M7158-00

BRKT,HNS.SUB

2

34

KLD-M7159-01

BRKT,HNS 1

1

35

KLD-M7160-00

BRKT, HNS 2

1

36

KLD-M71H9-00

COUPLING

1

37

90440-01J030

CIRCLIP

2

38

98902-03006

SCREW BINDING HEAD

11

39

99480-03008

PIN,PARALLEL

2

40

99480-04008

PIN,PARALLEL

2

41

99480-04010

PIN,PARALLEL

6

42

99480-06012

PIN,PARALLEL

2

43

KLD-M7174-00

PIN,SPRING

1

44

91312-03008

BOLT HEX,SOCKET HEAD

10

45

KLD-M7171-01

BRKT,SPG Z

1

46

91312-04008

BOLT HEX,SOCKET HEAD

1

47

92012-04008

BOLT, BOTTON HEAD

1

42

24

29

12

14

26

19

18

3

8

21

37

28

43

25

37

27

22

39

11

41

44

40

8

17

31

39

8

41

40

7

46

41

45

23

6

6

44

4

1

16

38

8

36

5

34

13

7

32

38

2

2

30

33

38

15

20

38

33

2

13

9

10

30

38

35

Z2-axis (for Left Head)

Head Section

KLM-1206

5-4

NO

Parts_No.

Parts_Name

Q_ty

Remarks

Compati

Revision_No._date

1

$NK-3N

NYLON CLIP

1

2

90562-13J100

SPACER

4

3

90933-02J605

BEARING

1

4

90990-12J006

SCREW, BIN. HEAD W/W

1

5

90K24-033204

AC SERVO MOTOR

1

Z2-axis Drive for "Secondary Left-side Head"

6

91312-03010

BOLT HEX,SOCKET HEAD

6

7

91312-03012

BOLT HEX,SOCKET HEAD

6

8

91312-03020

BOLT HEX,SOCKET HEAD

14

9

91312-04006

BOLT HEX,SOCKET HEAD

4

10

91312-04020

BOLT HEX,SOCKET HEAD

1

11

91312-05016

BOLT HEX,SOCKET HEAD

4

12

91312-05020

BOLT HEX,SOCKET HEAD

2

13

92012-04006

BOLT, BOTTON HEAD

8

14

92902-05200

WASHER,PLAIN

2

15

95302-04600

NUT HEXAGON

1

16

KHN-M712A-00

BEARING

1

17

KJX-M7106-10

DAMPER LOW

1

18

KJX-M711P-00

CIRCLIP 5

1

19

KJX-M712G-00

PLATE BRG.

1

20

KLD-M66N4-20

HNS,R-FLEX（2V-R2)

1

21

KLD-M7102-00

PLATE HEAD

1

22

KLD-M7103-00

LM GUIDE

1

23

KLD-M7106-00

DAMPER

1

24

KLD-M7110-00

HOLDER Z

1

25

KLD-M7112-00

HOLDER NUT

1

26

KLD-M711N-00

HOLDER BRG

1

27

KLD-M7121-00

BALL SCREW

1

28

KLD-M713P-20

SPRING RETURN

1

29

KLD-M7173-00

GUIDE,SPRING

1

30

KLD-M713R-00

SHEET,RUBBER

2

31

KLD-M7151-02

BRKT,SPRING Z

1

32

KLD-M7155-02

COVER,GEAR

1

33

KLD-M7158-00

BRKT,HNS.SUB

2

34

KLD-M7159-01

BRKT,HNS 1

1

35

KLD-M7160-00

BRKT, HNS 2

1

36

KLD-M71H9-00

COUPLING

1

37

90440-01J030

CIRCLIP

2

38

98902-03006

SCREW BINDING HEAD

11

39

99480-03008

PIN,PARALLEL

2

40

99480-04008

PIN,PARALLEL

2

41

99480-04010

PIN,PARALLEL

6

42

99480-06012

PIN,PARALLEL

2

43

KLD-M7174-00

PIN,SPRING

1

44

91312-03008

BOLT HEX,SOCKET HEAD

10

45

KLD-M7172-01

BRKT,SPG & HNS

1

46

91312-04008

BOLT HEX,SOCKET HEAD

2
