YC8-KLM-000_PartsList.pdf - 第21页
5 4 3 6 7 2 1 Nozzle Nozzle Section KLM-1206 6-1 NO Parts_No. Parts_Name Q_ty Remarks Compati Revision_No._date 1 KV7-M7730-00 NOZZLE 63A 1 2 KV7-M7741-00 BODY ,NOZZLE 64A 1 3 90990-17J013 O-RING 1 4 KV7-M7751-00 BODY ,N…
4
5
28
13
3
13
21
1
28
29
15
13
11
13
31
30
23
17
27
8
10
9
7
18
18
11
2
26
25
22
14
16
20
6
19
12
24
Vacuum Ejector
Head Section
KLM-1206
5-6
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLD-M7157-11
BRKT,HNS.
1
2
KLD-M7166-10
BKT.VALVE
1
3
KLD-M7167-01
BKT.CAMERA CABLE
1
4
KLD-M7182-00
EJECTOR
1
in case of "2 Heads Installation"
5
KLD-M7182-10
EJECTOR
1
in case of "1 Head Installation"
6
KGS-M7176-00
VALVE
1
7
KM1-M4592-13
VAC SENSOR BOARD ASSY
2
in case of "1 Head", [1] decreased
8
KV7-M8167-00
JOINT,VACUUM SENSOR
2
ditto
9
90200-10J030
O-RING
2
ditto
10
90562-13J100
SPACER
2
ditto
11
91312-03006
BOLT HEX,SOCKET HEAD
4
in case of "1 Head", [2] decreased
12
91312-03016
BOLT HEX,SOCKET HEAD
2
13
91312-04006
BOLT HEX,SOCKET HEAD
7
14
91312-04030
BOLT HEX,SOCKET HEAD
2
15
95302-05600
NUT HEXAGON
2
in case of "1 Head", [1] decreased
16
$KM-05
MUFFLER
1
17
$SL8-01
JOINT
1
18
$TL4-M3M
JOINT
2
in case of "1 Head", [1] decreased
19
$TL4-M5
JOINT
1
20
$TL6-M5M
JOINT
1
21
$TS4-M5
JOINT
2
22
$USD8-6
JOINT
1
23
$UT4M
JOINT
2
24
$UY4
JOINT
1
in case of "2 Heads", Air-Dividing-Joint
25
$UP4
JOINT
1
in case of "1 Head", Air-Stopping-Plug
26
$UYD10-8
JOINT
1
27
K40-M8598-00
PLUG 1
1
28
KJH-M7111-A0
EJECTOR
2
for Maintenance, Spare-Parts
29
KGA-M7111-H0
VALVE
2
ditto
30
KJH-M7111-G0
VALVE
2
ditto
31
KJH-M71G4-00
BIT
2
ditto
17
36
14
1
8
40
15
41
16
22
37
21
35
37
35
9
36
4
32
4
5
28
39
2
29
40
19
2
10
27
41
22
31
18
23
34
33
30
7
18
38
6
23
3
20
6
27
24
25
19
6
26
13
3
6
11
12
7
17
36
14
1
8
40
15
41
16
22
37
21
35
37
35
9
36
4
32
4
5
28
39
2
29
40
19
2
10
27
41
22
31
18
23
34
33
30
7
18
38
6
23
3
20
6
27
24
25
19
6
26
13
3
6
11
12
7
Nozzle Changer Base
Nozzle Section
KLM-1206
6-2
OLD
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-4N
NYLON CLIP
5
2
$SC4-M5A
SPEED CONTROLLER
2
3
90933-02J063
BEARING
2
4
90990-02J003
SET, SCREW
12
5
90990-41J123
COLLAR
2
6
90990-41J129
COLLAR
4
7
91312-03010
BOLT HEX,SOCKET HEAD
2
8
KGR-M9611-00
BRACKET,ANC.
1
9
91312-03030
BOLT HEX,SOCKET HEAD
2
10
91312-04010
BOLT HEX,SOCKET HEAD
2
11
91312-04016
BOLT HEX,SOCKET HEAD
1
12
91312-04022
BOLT HEX,SOCKET HEAD
1
13
91312-05020
BOLT HEX,SOCKET HEAD
1
14
91317-04008
BOLT HEX,SOCKET HEAD
5
15
91317-04020
BOLT HEX,SOCKET HEAD
4
16
91317-05016
BOLT HEX,SOCKET HEAD
3
17
91317-06020
BOLT HEX,SOCKET HEAD
2
18
92012-04010
BOLT, BOTTON HEAD
2
19
92902-04200
WASHER,PLAIN
3
20
92902-05200
WASHER,PLAIN
1
21
KGR-M9653-00
BRACKET 1
1
22
98902-03006
SCREW BINDING HEAD
12
23
KHW-M916A-00
BUSH
2
24
KHW-M916E-00
BUSH
1
25
KHW-M916G-00
COLLAR, JOINT
1
26
KHW-M916H-00
JOINT, CYL.
1
27
KHY-M9605-10
CYLINDER
1
28
KHY-M9613-00
BLOCK,CYLINDER
1
29
KHY-M9615-00
PLATE,CYLINDER
1
30
KHY-M9627-00
BLOCK,LINK
1
31
KHY-M9628-00
COLLAR,LINK
1
32
KHY-M9630-00
HOOK,BEARING
1
33
KHY-M9631-00
COLLAR,FLOATING
1
34
KHY-M9632-00
BLOCK,FLOATING
1
35
KLM-M655A-00
SWITCH OPTICAL,1
1
Base unit
35-1
KLM-M655A-01
SWITCH OPTICAL,1
1
Base unit
OK
MSY0088-2021/3/23
36
KLM-M655B-00
FAIBER ASSY
12
37
KLM-M655C-00
SWITCH OPTICAL,2
11
Extension unit
37-1
KLM-M655C-01
SWITCH OPTICAL,2
11
Extension unit
OK
MSY0088-2021/3/23
38
KLM-M9614-00
STOPPER,CYLINDER
1
39
KLM-M9652-00
PLATE,CLAMP
1
40
KLM-M9654-00
PLATE,GUIDE
2
41
KLM-M965A-00
COVER 1,SENSOR
2
