YC8-KLM-000_PartsList.pdf - 第9页
33 27 34 11 31 28 3 32 17 30 8 16 15 20 4 20 24 29 25 1 2 7 6 21 31 3 6 21 9 22 26 6 14 26 26 6 36 6 7 23 25 24 36 29 6 13 12 18 15 35 19 27 11 5 10 X-axis Drive / Beam Moving-axis Section KLM-1206 4-1 NO Parts_No. Parts…
1
2
13
30
10
23
7
18
9
32
28
33
34
8
24
25
29
15
14
6
27
20
8
5
22
11
31
16
12
19
12
21
35
4
26
6
6
3
17
Feeder Holder 14 Lanes
Feeder Holder Section
3-1
KLM-1206
* in case of "Built-in-Left"
* in case of "Built-in-Right"
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLM-M3400-A0
FEEDER PLATE A14
1
in case of "Built-in-Left"
2
KLM-M3400-B0
FEEDER PLATE B14
1
in case of "Built-in-Right"
3
$TSS4-01
JOINT
1
4
$UKM4-01
JOINT
1
5
91312-03020
BOLT HEX,SOCKET HEAD
4
6
91312-04006
BOLT HEX,SOCKET HEAD
8
7
91312-04008
BOLT HEX,SOCKET HEAD
4
8
91312-04010
BOLT HEX,SOCKET HEAD
6
10
91312-06014
BOLT HEX,SOCKET HEAD
4
11
91312-06020
BOLT HEX,SOCKET HEAD
4
12
98702-03006
SCREW,FLAT HEAD
14
13
KHY-M3430-10
LABEL,FEEDER 60-12P
1
A0 : [1]<==>[14] / B0 : [15]<==>[28]
15
KHY-M66TE-00
HNS,F.CTRL - FDR.
14
16
KKG-M371R-00
RAIL GUIDE 12P
1
8 Lanes
17
KKG-M372R-00
GUIDE,FEEDER UNDER
2
18
KKT-M340C-00
PLATE,FRONT
1
19
KKT-M340E-00
RAIL GUIDE 12P
1
6 Lanes
20
KKT-M340G-00
SHAFT GUIDE
1
21
KKT-M4476-00
FDR.CTRL.BOARD ASSY
1
22
KLM-M3402-00
SLOPE,UNDER
2
23
KLM-M3T0E-00
TAPE GUIDE
1
24
98902-03004
SCREW BINDING HEAD
12
25
KLM-M3401-00
PLATE,FEEDER 12-14
1
26
98902-03006
SCREW BINDING HEAD
4
27
99480-04012
PIN,PARALLEL
1
28
KLM-M3404-00
STAND,FEEDER PLATE
2
29
99480-06012
PIN,PARALLEL
2
30
99480-06014
PIN,PARALLEL
1
31
99480-06020
PIN,PARALLEL
4
32
KLM-M3407-00
BASE,SIDE PLATE
2
33
KLM-M340H-00
COVER 2
1
34
KLM-M340J-00
PLATE,CONNECTOR
1
35
KLM-M340K-00
COVER 1
1
33
27
34
11
31
28
3
32
17
30
8
16
15
20
4
20
24
29
25
1
2
7
6
21
31
3
6
21
9
22
26
6
14
26
26
6
36
6
7
23
25
24
36
29
6
13
12
18
15
35
19
27
11
5
10
X-axis Drive / Beam
Moving-axis Section
KLM-1206
4-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
12
2
90990-11J001
SCREW, PAN HEAD W/W
12
3
90990-11J003
SCREW, PAN HEAD W/W
6
4
90990-26J008
BEARING
1
5
90K63-511403
AC SERVO MOTOR
1
6
91312-04014
BOLT HEX,SOCKET HEAD
38
7
92012-04025
BOLT,BUTTON HEAD
4
8
91312-05014
BOLT HEX,SOCKET HEAD
4
9
91312-05018
BOLT HEX,SOCKET HEAD
4
10
91312-06018
BOLT HEX,SOCKET HEAD
4
11
91312-06025
BOLT HEX,SOCKET HEAD
8
12
KHN-M2221-00
SUPPORT UNIT
1
13
91317-04012
BOLT HEX,SOCKET HEAD
4
14
KLD-M2261-A0
HOLDER,HEAD R ASSY.
1
15
92A08-04304
SCREW SET
2
16
KG2-M9173-00
LOCK NUT
1
17
KGK-M2276-S0
X-AXIS GUIDE SET
1
18
KGS-M2628-00
LOCK NUT
1
19
KHN-M2241-00
HOLDER,MOTOR X
1
20
KHN-M2248-00
SPACER
2
21
90K81-200006
CAP M4
22
22
KLD-M2271-00
BALL SCREW
1
23
KHN-M224D-00
SPACER
1
24
KHN-M224J-00
COLLAR A
4
25
KHN-M224K-00
COLLAR B
4
26
KHN-M22F4-00
WASHER,SWR04
16
27
KHN-M22F6-00
WASHER,SWR06
8
28
KHY-M2240-00
SLEEVE,BRG.
1
29
KHY-M224H-00
DAMPER
2
30
KHY-M2282-00
DOG.ORIGIN
1
31
KHY-M2283-00
DOG,SECOND LIMIT
2
32
KLD-M220D-00
TAPE, X-AXIS
2
33
KLD-M2211-00
FRAME R, X AXIS
1
34
KLD-M2242-00
HOLDER,BRG.
1
35
KM0-M2220-00
COUPLING, X-AXIS
1
36
99480-06018
PIN,PARALLEL
2
28
41
24
12
30
7
13
22
27
13
14
23
13
3
7
1
14
14
31
29
25
13
4
21
39
40
6
26
16
33
34
20
37
10
38
18
9
19
10
35
7
36
10
42
8
2
32
5
9
15
11
17
7
X-axis Neighbor
Moving-axis Section
KLM-1206
4-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KJX-M7192-00
HEAD I/O BOX
1
2
$NK-3N
NYLON CLIP
12
3
90563-03J160
SPACER
4
4
90990-01J037
BOLT HEX,SOCKET HEAD
6
5
90990-11J001
SCREW, PAN HEAD W/W
12
6
91312-04006
BOLT HEX,SOCKET HEAD
8
7
91312-04008
BOLT HEX,SOCKET HEAD
13
8
91312-05008
BOLT HEX,SOCKET HEAD
6
9
91312-05012
BOLT HEX,SOCKET HEAD
4
10
91312-05018
BOLT HEX,SOCKET HEAD
12
11
91312-06016
BOLT HEX,SOCKET HEAD
2
12
97602-03108
SCREW PAN HEAD W/WASHER
4
13
97602-03306
SCREW PAN HEAD W/WASHER
22
14
98702-03004
SCREW,FLAT HEAD
12
15
98902-04006
SCREW BINDING HEAD
4
16
99480-06018
PIN,PARALLEL
2
17
KGS-M2256-00
GRIP
1
18
KHN-M22F5-00
WASHER,SWR05
8
19
KHY-M2252-02
STOPPER
1
20
KHY-M2284-00
BRACKET,SENSOR
1
21
KHY-M652X-00
SENSOR,XT ASSY
1
22
KHY-M5890-40
HEAD SERVO BOARD ASSY
3
23
KJX-M457R-01
HEAD I/O1 BOARD ASSY
1
24
KJX-M457U-01
HEAD I/O2 BOARD ASSY
1
25
KJX-M457W-01
HEAD I/O3 BOARD ASSY
1
26
KJX-M7191-10
FRAME,I/O BOX
1
27
KJX-M7192-30
POST3
1
28
KJX-M7192-40
POST4
1
29
KJX-M7196-00
BRACKET,FAN
1
30
KJX-M719A-00
PLATE 2,GUIDE HARNESS
1
31
KLD-M220D-00
TAPE, X-AXIS
2
32
KLD-M2237-00
BRACKET,HEAD SERVO
1
33
KLD-M2238-00
BRACKET,L
1
34
KLD-M2239-00
BRACKET,R
1
35
KLD-M223F-00
STAY,R HNS.
1
36
KLD-M226B-00
COVER BACK, X AXIS
1
37
KLD-M227G-00
COVER,B.S.
1
38
KLD-M2291-00
PLATE,HEAD SERVO
1
39
KLD-M2A01-01
PLATE,HEAD
1
40
KHY-M652W-00
SENSOR,XORGASSY
1
41
KLD-M2A02-01
STAY,HANDLE
1
42
KV7-M7165-00
SEAL DON'T TOUCH
2
