GEM Manual for DEK Printers SECS II Implementation
Issue 1.6 January 22, 2018 Page 60 of 171
Equipment Initiated Messages:
Primary Description Reply Description
S1F1 Are You There Request S1F2 On-Line Data
S1F13 Establish Communications Request S1F14 ECR Acknowledge
S2F17 Date & Time Request S2F18 Date & Time Data
S5F1 Alarm Report Send S5F2 Alarm Report Acknowledge
S6F1 Trace Data Send S6F2 Trace Data Acknowledge
S6F5 Multi-block Data Send Inquire S6F6 Multi-block Grant
S6F11 Event Report Send S6F12 Event Report Acknowledge
S7F1 Process Program Load Inquire S7F2 Process Program Load Grant
S7F3 Process Program Send S7F4 Process Program Acknowledge
S7F5 Process Program Request S7F6 Process Program Data
S9F1 Unrecognised Device ID
S9F3 Unrecognised Stream Type
S9F5 Unrecognised Function Type
S9F7 Unrecognised Illegal Data
S9F9 Transaction Timer Timeout
S9F11 Data Too Long
S9F13
Conversation Timeout
S10F1 Terminal Request S10F2 Terminal Request Acknowledge
GEM Manual for DEK Printers SECS II Implementation
Issue 1.6 January 22, 2018 Page 61 of 171
5.2 SECS II VARIABLE DATA DEFINITIONS
This section gives definitions of the data items required in the SECS II streams and functions
implemented by the DEK Printer. The definitions are in alphabetical order of symbol name.
Data Item Description Values Format
ABS Any binary string.
binary*1
ACKC5 Acknowledge code, responding to alarm
enable / disable or notification.
0 = Accepted.
>0 = Denied.
binary*1
ACKC6 Acknowledge code, responding to trace or
event report send.
0 = Accepted and done.
>0 = Error.
binary*1
ACKC7 Acknowledge code, responding to process
program transfer, or delete.
0 = Done.
1 = Permission denied.
2 = Length error.
4 = PPID not found.
6 = File Format error
7-63 = Reserved.
64 = Process program
parameter error.
65 = Format Error
binary*1
ACKC10 Acknowledge code, responding to text
message.
0 = Accepted for display.
1 = Will not display.
unsigned int*1
ACKC13 Return code for secondary messages
used by S13F4.
0 = Data set opened
successfully.
1 = 265 is not ready.
2 = Unknown data set.
3 = Invalid check point.
4 = Invalid length.
5 = File error.
6 = Processing error.
7 = Cannot continue.
8 = End of file.
binary*1
ALCD Alarm code. Bit 8 = 1 is alarm set.
Bit 8 = 0 is alarm clear.
binary*1
ALED Alarm enable / disable code.
Bit 8 = 1 to enable alarm
Bit 8 = 0 to disable alarm
binary*1
ALID Alarm identification.
See chapter 6 for a list.
unsigned int*1
ALTX Alarm text. See chapter 6.
ASCII
∗≤
40
ATTRDATA Attribute Data, the value of a requested
attribute for a particular object id
Any text string
ASCII
∗≤
80
ATTRID Attribute Identifier, specifies which attribute
to return for an object
0 = Name
1 = Current Value
unsigned int*4
ATTRRELN Attribute relationship qualifier
Used by S14F1 - Not currently implemented
CEED Collection event enable / disable code. >0 = Enable.
0 = Disable.
boolean
GEM Manual for DEK Printers SECS II Implementation
Issue 1.6 January 22, 2018 Page 62 of 171
Data Item Description Values Format
CEID Collection event identity. See chapter 7 for list. unsigned int*4
CKPNT Check Point, (data block number)
used by S13,F3 F6.
unsigned int*4
COMMACK Establish communications request
acknowledge code.
0 = Accepted.
1 = Denied, try again.
binary*1
CPACK Command parameter acknowledge. 1 = CPNAME unknown.
2 = CPVAL bad value.
3 = CPVAL bad format.
4 = No screen in chase.
5 = No autochanger.
6 = Screen loaded.
7 = Screen unloaded.
8 = No Clean Screens.
9 = No Screens in Autochanger.
10 = Autochanger is full.
11 = No screen change
mechanism.
binary*1
CPNAME Command parameter name. See appendix A.
ASCII *
≤
20
CPVAL Command parameter value. See appendix A.
ASCII*
≤
20
DATAID Unique identification of transferred data set.
Incremented for each transfer transaction.
Any 4 byte integer value.
Except in S6F7 where it is 2
bytes.
unsigned int*4
DATALENGTH Number of bytes to be sent. Ignored.
unsigned int
DRACK Define report acknowledge code.
0 = Accepted.
1 = Denied, no space.
2 = Denied, bad format.
3 = Denied, RPTID exists
already.
4 = Denied, unknown VID.
binary*1
DSID Data Set Identifier
Used by S6F8
0 = Management data.
1 = Event Data.
2 = System Data.
signed int*2
DSNAME Data set name. “EVENT LOG” ASCII*10
DSPER Trace data sampling period. Hhmmss ASCII*6
DVNAME Data value name. 0 = Current process program.
1 = Operator name.
2 = Counts.
3 = Batch start time.
4 = Session start time.
5 = Waiting times.
6 = Running times.
7 = Setup times.
8 = Down times.
9 = Recovery times.
10 = Maintenance times.
signed int*2
DVVAL Data value. Depends on the
data type of
DVNAME.
