9|Spare and wear parts 9.4.3 Double pot positioning system (dual track) Overview Fig.165: EM113-24-00 Ersa GmbH Operating Instructions_VF366_en|Rev. 14|30/11/2017 411/551
9|Spare and wear parts
9.4.2 Z-axis single pot
1
2
4
2
21
1
3
Fig.164: EM113-21-01-00
Pos Description Item number A B
1 Tooth belt 425-5M-15 6ZR0425-5M-15 x
2 Tensioning kit 112207 x
3 Servo drive with resolver 23567 x
4 Lifting spindle, complete (Cannot be shipped separately) 209659 x
Ersa GmbH Operating Instructions_VF366_en|Rev. 14|30/11/2017 410/551
9|Spare and wear parts
9.4.3 Double pot positioning system (dual track)
Overview
Fig.165: EM113-24-00
Ersa GmbH Operating Instructions_VF366_en|Rev. 14|30/11/2017 411/551
9|Spare and wear parts
Double solder pot positioning system, view [Z]
2 43 1
3 4
Fig.166: EM113-24-00a
Pos Description Item number A B
1 Tooth belt 25AT10 L = 2600 mm 216462 x
3 Motor/gear combination --> 2010 175816 x
3 Motor/gear combination 2010 --> 191607 x
4 Motor/gear combination --> 2010 175817 x
4 Motor/gear combination 2010 --> 191608 X
5 Energy chain 188761 x
6 Energy chain 188750 x
7 Energy chain 188754 x
