2-10 2 asic operation 2. Operation screen and buttons The basic configuration and operation methods of the software screens are explained in this section. Please read through this section before operating the machine. …
2-9
2
asic operation
Code Error name and description
Ea29922
FEEDER CART(REAR1) IS NOT SET
State Emergency stop function is activated.
Cause Feeder cart (rear 1) is not set.
Action
Set the Feeder Cart or close the Cart Cover, and press the READY button to re-enable the machine.
The "EMERGENCY STOP" light will go off.
Ea29923
FEEDER CART(REAR2) IS NOT SET
State Emergency stop function is activated.
Cause Feeder cart (rear 2) is not set.
Action
Set the Feeder Cart or close the Cart Cover, and press the READY button to re-enable the machine.
The "EMERGENCY STOP" light will go off.
2-10
2
asic operation
2. Operation screen and buttons
The basic configuration and operation methods of the software screens are explained in this section. Please
read through this section before operating the machine.
2.1 Basic configuration of operation screen
The operation screen can be divided into the "Status area", "Main menu button area" and "Submenu button and
parameter area" as shown below.
Main menu button area 1
Main menu button area 2
Main menu button area 3
Status area
Operation screen basic configuration
Setup screen
Submenu button and parameter area
24200-L1-00
n
Area on screen
Status area
Displays the current machine status on the left end, the selected board
name in the middle, and the number of boards that have been produced
on the right end.
Main menu button area 1
Shows the main menu buttons used to operate the machine. The
submenu button and parameter area will change according to the
selected main menu button.
Main menu button area 2
Shows the menu buttons used to call up auxiliary functions of the
machine.
Main menu button area 3
Shows the [Help] button to call up the help screen and also the [Off]
button to quit the software.
Submenu button and parameter area
Displays the submenu buttons and parameters for machine operation
and data setting. This area will change according to the selected main
menu button.
2-11
2
asic operation
n
Various buttons and parameter input boxes
Various types of buttons, selection tabs and parameter input boxes are used on the operation screen.
1
1
2
3
4
5
6
Operation screen basic elements
Mark screen
Parameter listData No. list
24201-L1-00
1. Scroll bar and button (up/down, left/right)
Use the scroll bars or arrow buttons to see hidden items in the data No. list or parameter list.
2. Operation button
Press these buttons to open the next operation screen or dialog box.
3. Line up/down button
Use these buttons to move the cursor up or down through the data No. list or parameter list.
4. Parameter input box
Select, enter or edit parameters here. When the keyboard is used, double-click on a parameter input box to enter or edit
the data.
When a touch screen (option) is used, press the [Edit] button on the lower right of the parameter list. The edit box then
pops up for data input and editing.
5. Selection tab
Select this tab to switch the parameter input screen.
6. Assistant screen
Shows an illustration or information useful for parameter input or editing.
Alphabet characters shown in the parameter list and in the illustration on this screen correspond to each other.
