Installation Manual, Station Software Version 505.04 SP2 Edition 11/2007
57 of 154
Information: The original partitions are displayed correctly, but to not function correctly.
Simply reformatting the disk does not solve the problem.
- Create with FDISK follwowing partitions:
Partition Status Typ Mbyte
C:1 A PRI DOS 50
2 EXT DOS 450
- Restart the computer (Press simultaneously Ctrl + Alt + Del).
- Now the 505 software can be installed in the normal manner for a new hard disk.
Note:
You find more details concerning the BIOS setting, operating system etc. in our Technical
Information that are online available via the SIEMENS DMS (
www.siplace.com ).
4.4.1.1 Starting the BIOS Setup
To start the BIOS setup, wait for the following message to appear on the screen after the system
has been booted and then press the <F2> key.
PowerBIOS Version 1.00
Copyright(C) 1984-1995, Award Software, Inc.
12/06/96 - Intel - 82430HX
AMS-M54 V 1.00
┌────────────────────────────────────────────────────────────────────────┐
│ CPU Type...............................................Pentium xxx MHz │
│ Math CoProcessor..............................................Internal │
│ . │
│ . │
│ . │
│ . │
│ . │
│ . │
│ . │
│ . │
└────────────────────────────────────────────────────────────────────────┘
Press F2 to enter setup
Installation Manual Station Software Version 505.04 SP2
58 of 154
Main menu
The BIOS Setup has the following initial menu:
┌────────────────────────────────────┐
│ Award Software International, Inc. │
│ PowerBIOS 1.00 Setup │
│ ┌──────────────────┐ │
│ │ System Security │ │
│ │ Date and Time │ ╔══════╗ │
│ │ AT Hard Disk │ ║ OPEN ║ │
│ │ Floppy Disk │ ╚══════╝ │
│ │ Boot Features │ │
│ │ Standard Chipset │ ┌──────┐ │
│ │ Advanced Chipset │ │Cancel│ │
│ │ Peripherals │ └──────┘ │
│ │ PCI Setup │ │
│ │ IMC Interrupts │ │
│ │ COM Redirection │ │
│ │ IMC Miscellaneous│ │
│ │ │ │
│ └──────────────────┘ │
│ Press [F4] key to toggle color │
│ Press [F1] key for help │
└────────────────────────────────────┘
Keyboard operation in the BIOS Setup
Key Action
CURSOR-DOWN, CURSOR-UP Selects the next/previous Setup page.
RETURN Displays the selected Setup page (if "OPEN" is active) or
terminates Setup (if "Cancel" is active)
ESC Ends Setup
TAB, SHIFT-TAB Activates the next/previous button.
F1 Calls context-sensitive Help system: Opens a help window for
the entry that is currently selected
F4 Switches from color to black and white display in the BIOS
Setup.
The current setting is saved when Setup is ended, and remains
set the next time Setup is started.
Installation Manual, Station Software Version 505.04 SP2 Edition 11/2007
59 of 154
4.4.1.2 Terminating the BIOS Setup
From the main menu, use the ESC key to call the exit menu:
┌───────┤ Setup Exit ├─────────┐
│ │
│ Do you wish to save │
│ the changes to CMOS? │
│ │
│ ╔══════╗ ┌──────┐ ┌──────┐ │
│ ║ SAVE ║ │ EXIT │ │RETURN│ │
│ ╚══════╝ └──────┘ └──────┘ │
│ │
│ Press [F1] key for help │
└──────────────────────────────┘
Choose "SAVE" to save the set parameters.
Choose "EXIT" to exit Setup. The old parameters remain set.
Choose "RETURN" to return to the main menu of the Setup.
More information about using the Setup and the parameters on the various Setup pages can be
found in the following sections.
4.4.1.3 Setup page "System Security"
┌───────────┤ System Security ├──────────────┐
│ │
│ ┌Device Security───────────┐ ╔══════╗ │
│ │[ ] Floppy Disk Read Only │ ║ OK ║ │
│ │[ ] Hard Disk Read Only │ ╚══════╝ │
│ └──────────────────────────┘ ┌──────┐ │
│ │Cancel│ │
│ ┌Password──────────────────┐ └──────┘ │
│ │[ ] Enter Setup │ │
│ │[ ] System Boot │ │
│ └──────────────────────────┘ │
│ Press [F1] key for help │
└────────────────────────────────────────────┘
