Nachrüstanleitung Spleißstellenerkennung Basispaket + Tischcontroller SIPLACE HF
Ausgabe 08/2005
22
1.9.2 Installation der Treibersoftware
: Melden Sie sich als lokaler Administrator an.
: Öffnen Sie die MS-DOS-Eingabeaufforderung.
: Legen Sie die mitgelieferte Treiberdiskette in den Stationsrechner ein.
: Starten Sie A:\InstCSER.exe.
Der Treiber wird installiert.
: Entnehmen Sie die Diskette.
: Starten Sie den Bestückautomaten neu.
1.9.3 Test der Treibersoftware
: Öffnen Sie das Menü START / Einstellungen / Systemsteuerung / Anschlüsse.
In diesem Menü müssen jetzt zusätzlich die Schnittstellen COM 3 bis 5 sichtbar sein. 1
1
: Installieren Sie die SMV-Software, die Tracability-Software und die Füllstands-Softeware
(siehe entsprechende Installationsanleitungen).
1
1
Retrofit instructions Splice Detection Basic Package + Table Controller SIPLACE HF-series
08/2005 Edition
23
2 Retrofit Instructions Splice detection
Basic package and Table controller
SIPLACE HF-series
2.1 Overview
This manual describes how to install a table controller for detecting splices on a changeover table
of a SIPLACE HF placement machine. 2
2
Abb. 2.10 - 1 SIPLACE HF component changeover table
Retrofit instructions Splice Detection Basic Package + Table Controller SIPLACE HF-series
08/2005 Edition
24
2.2 Safety instructions
WARNING
Comply with the higher ranking "Safety Instructions" in Chapter "Operational Safety" in the User
Manual and Service Manual
The placement machines SIPLACE are powered by mains voltage.
Portions of the system are therefore conducting dangerous electricity, inside the machine even
while the master switch is turned off.
Death, serious injury or considerable damage may result if these automatic placement systems
are handled incorrectly.
After you have properly carried out the shut-down of the operating system:
Before all work the machine must be turned off at the main switch and isolated from the mains. In
addition, the compressed air supply must be turned off at the main valve of the compressed air
unit in the machine base and the compressed air lines must be bled by actuating the needle valve
at the compressed air unit.
Danger: For anyone wearing a heart pacemaker it is not permitted to work near linear motors, as
described in detail in the User Manual and the Service Manual, Chapter "Special Safety Instruc-
tions when working in vivinty of powerful magnetic fields" .
Obey the applicable accident prevention regulations, DIN standards and special safety codes of
your country at all times. DIN EN 60204 must be adhered to during all work inside the machine
base.
Follow the instructions regarding residual voltages in Chapter "Operational Safety".
Comply with regulations on ESDs (see Chapter "Operational Safety").
During the work of retrofitting secure the machine conscientiously against other personnel and
prevent it from being turned back on without authorization, as described in the User Manual in the
chapter "Locking the Machine...".
There is additional, higher risk of accident when working with the SITEST program.
The SITEST program is only to be started by personnel who are authorized to do so. 2
2
