Mounter behaves like below on each [Mount Mode] / [Transfer Mode].
Mount mode
Transfer mode
Parallel Lanes Alternate Lanes
Asynchronous Transfer
The front head mounts front lane
and rear head mounts rear lane.
Front lane and rear lane are
mounted in order. While mounting
one side lane, the opposite lane
can transfer boards. This cuts
down transfer loss time.
Synchronous Transfer
The timing of start and complete
mounting are synchronized.
If one side of heads completes
mounting earlier, it helps the
other one in order to shorten
cycle time.
(This cannot be selected)
When mount mode is [Alternate
Lanes], optimizer always outputs
the result with asynchronous
transfer.
(7)Result dialog is extended.
It is extended for combined board data.
• CT of each lane is displayed on [Line CT(sec)] ( Lane1 / Lane2 ).
• [Cycle Time + Transfer (sec)] is displayed on trace view. It is the total time of mount and
transfer.
It is different by mount mode.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50069
20/24
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50069
21/24
[Line CT (sec)]
Mount Mode /
Transfer Mode
[Line CT (sec)]
Parallel Lanes /
Asynchronous Transfer
Line CT of each lane is displayed (Lane1/Lane2).
Parallel Lanes /
Synchronous Transfer
It is the greater mount time of both lanes (mount time of front lane
and rear lane.) Lane CT of each lane is the same.
Alternate Lanes /
Asynchronous Transfer
It is the total of mount time of each lane (mount time of front lane
and rear lane). Lane CT of each lane is the same.
(Trace view)
Mount Mode /
Transfer Mode
[Cycle Time +
Transfer (sec)]
[Points]
[Fid.Mark Rec.Times]
[BadMark Rec.Times]
Other Items
Parallel Lanes /
Asynchronous Transfer
Value of each lane is
displayed
Parallel Lanes /
Synchronous Transfer
Cycle time with
transfer time is
displayed.
Total count of each
lane is displayed. The
value of both lane is
the same
Alternate Lanes /
Asynchronous Transfer
Cycle time without
transfer time is
displayed. (While
mounting one side
lane, the opposite
lane can transfer
boards.
Values of each lane
are displayed
Value of each lane is
displayed
