Product Engineering Division
SMT Section
Robotics Operations
YAMAHA MOTOR CO., LTD.
MDOC-SOFT50282
18/21
Table 4.2 Notice Timing
Notice timing Function
Power ON Displays the message when the first Return-to-Origin after
machine startup is completed.
* If feeders are on cart, the cart must be correctly set.
* When there is no correction value at the time of power-on,
Feeder MACS correction value is excluded.
Feeder ON/OFF Displays the message when attaching or removing a feeder
that requires maintenance.
* Includes the following timing.
- The cart clamp switch is turned ON/OFF by hand.
- Cart clamp ON at machine start-up.
- Cart clamp OFF at machine shutdown.
* When there is no correction value at the time of power-on,
Feeder MACS correction value is excluded.
Notice timing Function
Feeding count over Displays the message when feeding count exceeds the notice
count.
Once the message is displayed, it is not displayed again until
the board data is read or the feeder is removed (but displayed
on the other timing if selected as well).
Board change Displays the message at reading board data.
Reset Displays the message when [RESET] button is pressed.
Power OFF Displays the message when [OFF] button is pressed.
Time setting Displays the message at a given time, during auto-running or
not.
Product Engineering Division
SMT Section
Robotics Operations
YAMAHA MOTOR CO., LTD.
MDOC-SOFT50282
19/21
Table 4.3 Recommended Notice Count (Feeder maintenance period)
Notice Cnt (10,000times) Stop Cnt (10,000times)
Tape Type SS Feeder ZS Feeder SS Feeder ZS Feeder
4mm tape 5,000,000 5,000,000 7,500,000 7,500,000
8mm tape
12mm/16mm
tape
2,000,000 3,000,000
24mm tape
32mm tape 2,000,000 3,000,000
44mm tape
56mm tape
72mm tape
88mm tape
104mm tape
120mm tape
136mm tape
152mm tape
168mm tape
184mm tape
200mm tape
Product Engineering Division
SMT Section
Robotics Operations
YAMAHA MOTOR CO., LTD.
MDOC-SOFT50282
20/21
Table 4.4 Recommendation of Feeder MACS Correction Value/Pickup Error Rate
(Recommended cycle of feeder maintenance)
▲2
Notice Correct
(mm)
Stop Correct (mm) Notice
Pickup Err
Rate (%)
Stop Pickup
Err Rate (%)
Tape Type X Y X Y
4mm tape 0.200 mm 0.200 mm 0.000 mm 0.000 mm 1.00 % 0.00 %
8mm tape
12mm/16mm tape Not
supported
Not
supported
Not
supported
Not
supported
24mm tape
32mm tape
44mm tape
56mm tape
72mm tape
88mm tape
104mm tape
120mm tape
136mm tape
152mm tape
168mm tape
184mm tape
200mm tape
- Recommended value is common between SS feeder and ZS feeder.
