E-by SIPLACE CP12 & CP6 Return the Nozzles and Shut Down the Machine Part Exchange 3/3 CAUTION! Refer to safety inst ructions in user manual before working on the machine. ESD guidelines are to be followed Tool: Wear…

E-by SIPLACE CP12 & CP6 Return the Nozzles and Shut Down the Machine

Part Exchange

2/3

CAUTION! Refer to safety instructions in user manual before working on the machine.

ESD guidelines are to be followed

Tool: Wear Part: Consumables:

7. Click on "return to nozzle changer" icon. 8. Click on "setting options conveyor interface

and shut down" icon.

9. Click on "check and set user settings" icon.

10. Click on "machine service" icon. 11. Click on "sensors and functions" icon. 12. Click on "move gantry 1 to service posi-

tion" icon.

E-by SIPLACE CP12 & CP6 Return the Nozzles and Shut Down the Machine

Part Exchange

3/3

CAUTION! Refer to safety instructions in user manual before working on the machine.

ESD guidelines are to be followed

Tool: Wear Part: Consumables:

13. Press start button. 14. Click on "setting options conveyor inter-

face and shut down" icon.

15. Click on "shut down machine" icon.

16. Switch off the machine. 17. Open cover and check for obstruction be-

fore move.
