Fig. J1-7 エア配管 Air Piping 1 104-003 61 1 613 603 605 604 615 613 614 612 606 602 From Main Body From Main Body See Fig. J1-2 Key No.106 See Fig. J1-2 Key No.105 See Fig. J1-4 Key No.312 See Fig. J1-6 Key No.545 See Fig. …
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
531 221AA104 ROHS_HEX-SCT 2 2 M4L16 SW+FW 1091603D00-031
542 211G6019 BLOCK 1 1 1091603D00-042
543 211F9488 BRACKET 1 1 1091603D00-043
544 221AA099 ROHS_HEX-SCT 10 10 M3L6 SW+FW 1091603D00-044
545 23G30051 SENSOR 1 1 1091603D00-045
546 225F0467 PIPE_FITTINGS 2 2 1091603D00-046
547 211FE419 BRACKET 1 1 1091603D00-047
548 221DA057 MACHINE_SCREW 2 2 PAN M3L14 SW+FW
1091603D00-048
549 0916380A ASSY_VALVE 1 1 1091603D00-049
550 0916D70N BRACKET 1 1 1091603D00-050
551 221AA092 ROHS_HEX-SCT 9 9 M3L8 SW+FW 1091603D00-051
552 211AD832 COVER 1 1 1091603D00-052
553 0916D70P BRACKET 1 1 1091603D00-053
554 0916D70M BRACKET 1 1 1091603D00-054
555 211H0398 SHEET 1 1 1091603D00-055
556 211H0361 SHEET 1 1 1091603D00-056
557 225F0025 PIPE_FITTINGS 1 1 1091603D00-057
573 0916D60B CORD 1 1 left 1091603D00-073
573 0916D60C CORD 1 1 center 1091603D01-073
573 0916D60D CORD 1 1 right 1091603D02-073
574 0916D209 ACCESS_WIRING 10 10 1091603D00-074
575 0916D60A ACCESSORY_WIRING 2 2 1091603D00-075
Fig. J1
1104-004
Fig. J1-6
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-9
Fig. J1
HEAD 2
Fig. J1-7
エア配管
Air Piping
1104-003
611
613
603
605
604
615
613
614
612
606
602
From Main Body
From Main Body
See Fig. J1-2
Key No.106
See Fig. J1-2
Key No.105
See Fig. J1-4
Key No.312
See Fig. J1-6
Key No.545
See Fig. J1-4
Key No.323
See Fig. J1-5
Key No.472
See Fig. J1-6
Key No.549
601
B07
Y1718
Y1719
Fig. J1
多機能ヘッド
MULTI-FUNCTIONAL HEAD
UNIT-9
Fig. J1
HEAD 2
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
601 0916DG02 TUBE_D6 3 3 2091603G00-001
602 0916DG03 TUBE_D6 3 3 2091603G00-002
603 0916DG04 TUBE_D6 1 1 2091603G00-003
604 0916DG05 TUBE_D6 1 1 2091603G00-004
605 0916DG06 TUBE_D6 1 1 2091603G00-005
606 0916DG07 TUBE_D8 1 1 2091603G00-006
611 0916D70E BLOCK 1 1 3091603G01-001
612 225F0433 PIPE_FITTINGS 1 1 3091603G01-002
613 225F0467 PIPE_FITTINGS 5 5 3091603G01-003
614 225F0409 PIPE_FITTINGS 3 3 3091603G01-004
615 0921A05B AIR_LINE_EQPT 3 3 3091603G01-005
Fig. J1
1104-004
Fig. J1-7
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-9
Fig. J1
HEAD 2
