Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 402 21 1A9500 COVER 1 1 1 209210001P-002 403 221AA005 ROHS_HEX-SCT 2 2 2 M3L6 209210001P-003 404 221HA103 W ASHER 2 2 2 FW3 209210001P-004 405 221HA003 W ASHER 2 2 2 SW3 2…
Fig. K1-5
開閉扉
O/C Door
1104-003
425
425
424
436
421
422
428
430
431
428
430
431
432
429
426
427
447
467
423
423
427
445
445
444
441
442
448
450
451
448
450
451
452
449
446
456
443
447
443
465
465
464
461
462
472
476
469
466
463
467
463
484
485
486
484
485
486
483
482
481
402
416
405
404
403
415
413
471
470
468
471
470
468
420
419
418
412
420
415
413
419
417
420
419
417
420
419
418
411
C
C
492
491
497
494
498
493
495
496
C
DETAIL “C”
See Fig. K1-2
Key No.106
See Fig. K1-3
Key No.204
09210019
0921004M
0921004P
0921004N
0921001Q
0921001P
0921460H
B15516
B15515
S15517
H15542
Fig. K1
エレベータ部
ELEVATOR SECTION
UNIT-10
Fig. K1
ELEVATOR
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
402 211A9500 COVER 1 1 1 209210001P-002
403 221AA005 ROHS_HEX-SCT 2 2 2 M3L6 209210001P-003
404 221HA103 WASHER 2 2 2 FW3 209210001P-004
405 221HA003 WASHER 2 2 2 SW3 209210001P-005
411 09214602 ASSY_EE2_SEN 1 1 1 2092100019-001
412 09214603 ASSY_EE3_SEN 1 1 1 2092100019-002
413 0921E70E BRACKET 2 2 2 2092100019-003
415 211D9743 PLATE 2 2 2 2092100019-005
416 0921E70D BRACKET 1 1 1 2092100019-006
417 221AA005 ROHS_HEX-SCT 4 4 4 M3L6 2092100019-007
418 221AA009 ROHS_HEX-SCT 4 4 4 M3L14 2092100019-008
419 221HA103 WASHER 8 8 8 FW3 2092100019-009
420 221HA003 WASHER 8 8 8 SW3 2092100019-010
421 221E0471 BOLT 2 2 2 109210004M-001
422 4S1F0074 SWITCH_LIMIT 1 1 1 109210004M-002
423 226C0204 HANDLE 1 1 1 109210004M-003
424 0921E703 COVER 1 1 1 109210004M-004
425 211K2963 SUPPORT 2 2 2 109210004M-005
426 0921E704 SUPPORT 1 1 1 109210004M-006
427 0921E70N COVER 1 1 1 109210004M-007
428 221AA005 ROHS_HEX-SCT 9 9 9 M3L6 109210004M-008
429 221DA021 MACHINE_SCREW 2 2 2 PAN M4L6 109210004M-009
430 221HA103 WASHER 9 9 9 FW3 109210004M-010
431 221HA003 WASHER 9 9 9 SW3 109210004M-011
432 221HA004 WASHER 2 2 2 SW4 109210004M-012
436 0921A023 SHIELDING SEAL 1 1 1 109210004M-101
441 221E0471 BOLT 2 2 2 109210004N-001
442 4S1F0074 SWITCH_LIMIT 1 1 1 109210004N-002
443 226C0204 HANDLE 1 1 1 109210004N-003
444 0921E703 COVER 1 1 1 109210004N-004
445 211K2963 SUPPORT 2 2 2 109210004N-005
446 0921E704 SUPPORT 1 1 1 109210004N-006
447 0921E70M COVER 1 1 1 109210004N-007
448 221AA005 ROHS_HEX-SCT 9 9 9 M3L6 109210004N-008
449 221DA021 MACHINE_SCREW 2 2 2 PAN M4L6 109210004N-009
450 221HA103 WASHER 9 9 9 FW3 109210004N-010
451 221HA003 WASHER 9 9 9 SW3 109210004N-011
452 221HA004 WASHER 2 2 2 SW4 109210004N-012
456 0921A023 SHIELDING SEAL 1 1 1 109210004N-101
461 221E0471 BOLT 2 2 2 109210004P-001
462 4S1F0074 SWITCH_LIMIT 1 1 1 109210004P-002
463 226C0204 HANDLE 1 1 1 109210004P-003
464 0921E703 COVER 1 1 1 109210004P-004
465 211K2963 SUPPORT 1 1 1 109210004P-005
466 0921E704 SUPPORT 2 2 2 109210004P-006
Fig. K1
1104-004
Fig. K1-5
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-10
Fig. K1
ELEVATOR
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. K1-5
1104-004
Fig. K1
467 0921E70L COVER 1 1 1 109210004P-007
468 221AA005 ROHS_HEX-SCT 9 9 9 M3L6 109210004P-008
469 221DA021 MACHINE_SCREW 2 2 2 PAN M4L6 109210004P-009
470 221HA103 WASHER 9 9 9 FW3 109210004P-010
471 221HA003 WASHER 9 9 9 SW3 109210004P-011
472 221HA004 WASHER 2 2 2 SW4 109210004P-012
476 0921A023 SHIELDING SEAL 1 1 1 109210004P-101
481 211FE851 BRACKET 1 1 1 209210001Q-001
482 226J0001 MECH PARTS 1 1 1 209210001Q-002
483 211AE133 COVER 1 1 1 209210001Q-003
484 221AA006 ROHS_HEX-SCT 4 4 4 M3L8 209210001Q-004
485 221HA103 WASHER 4 4 4 FW3 209210001Q-005
486 221HA003 WASHER 4 4 4 SW3 209210001Q-006
491 211F9440 BRACKET 1 1 1 309210460H-001
492 4S1B0118 SWITCH_BUTTON 1 1 1 309210460H-002
493 0921E60M CORD 1 1 1 309210460H-003
494 9W310129 CORD 1 1 1 309210460H-004
495 23K10402 CASE_CONN 1 1 1 309210460H-005
496 4J300191 CAB_JOINTTERMIN 4 4 4 309210460H-006
497 23N20117 TUBE_WIRING 4 4 4 309210460H-007
498 23N20103 TUBE_WIRING 1 1 1 309210460H-008
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
