Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE Fig. K1-3 1 104-004 Fig. K1 265 23K10402 CASE_CONN 1 1 1 309210460K-005 266 4J300191 CAB_JOINTTERMIN 4 4 4 309210460K-006 267 23N201 17 TUBE_WIRING 4 4 4 309210460K-007 26…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
204 0921E30G FRAME 1 1 1 109210004L-004
205 211F8535 BRACKET 1 1 1 109210004L-005
206 211F8681 BRACKET 1 1 1 109210004L-006
208 211FE470 BRACKET 1 1 1 109210004L-008
209 211A9122 COVER 2 2 2 109210004L-009
210 226J0001 MECH PARTS 1 1 1 109210004L-010
211 226C0251 HANDLE 1 1 1 109210004L-011
212 221AA004 ROHS_HEX-SCT 2 2 2 M3L4 109210004L-012
213 221AA015 ROHS_HEX-SCT 18 18 18 M4L6 109210004L-013
214 221AA016 ROHS_HEX-SCT 4 4 4 M4L8 109210004L-014
215 221AA017 ROHS_HEX-SCT 2 2 2 M4L10 109210004L-015
216 221AA031 ROHS_HEX-SCT 2 2 2 M5L16 109210004L-016
217 221HA302 ROHS_WASHER 2 2 2 SW4 109210004L-017
218 221HA103 WASHER 2 2 2 FW3 109210004L-018
219 221HA104 WASHER 22 22 22 FW4 109210004L-019
220 221HA105 WASHER 2 2 2 FW5 109210004L-020
221 221HA003 WASHER 2 2 2 SW3 109210004L-021
222 221HA004 WASHER 24 24 24 SW4 109210004L-022
223 221HA005 WASHER 2 2 2 SW5 109210004L-023
228 226A0209 SEAL 1 1 1 109210004L-028
231 0921460E ASSY_EE14_SW 1 1 1 3092100016-001
232 0921E302 BRACKET 1 1 1 3092100016-002
233 0921E301 BRACKET 1 1 1 3092100016-003
234 221AA015 ROHS_HEX-SCT 2 2 2 M4L6 3092100016-004
235 221AA020 ROHS_HEX-SCT 3 3 3 M4L16 3092100016-005
236 221HA104 WASHER 5 5 5 FW4 3092100016-006
237 221HA004 WASHER 5 5 5 SW4 3092100016-007
241 0921460G ASSY_EE16_SW 1 1 1 3092100017-001
242 0921E302 BRACKET 1 1 1 3092100017-002
243 0921E301 BRACKET 1 1 1 3092100017-003
244 221AA015 ROHS_HEX-SCT 2 2 2 M4L6 3092100017-004
245 221AA020 ROHS_HEX-SCT 3 3 3 M4L16 3092100017-005
246 221HA104 WASHER 5 5 5 FW4 3092100017-006
247 221HA004 WASHER 5 5 5 SW4 3092100017-007
251 0921460F ASSY_EE15_SW 1 1 1 3092100018-001
252 0921E302 BRACKET 1 1 1 3092100018-002
253 0921E301 BRACKET 1 1 1 3092100018-003
254 221AA015 ROHS_HEX-SCT 2 2 2 M4L6 3092100018-004
255 221AA020 ROHS_HEX-SCT 3 3 3 M4L16 3092100018-005
256 221HA104 WASHER 5 5 5 FW4 3092100018-006
257 221HA004 WASHER 5 5 5 SW4 3092100018-007
261 211F8687 BRACKET 1 1 1 309210460K-001
262 4S1B0118 SWITCH_BUTTON 1 1 1 309210460K-002
263 0921E60M CORD 1 1 1 309210460K-003
264 9W310129 CORD 1 1 1 309210460K-004
Fig. K1
1104-004
Fig. K1-3
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-10
Fig. K1
ELEVATOR
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. K1-3
1104-004
Fig. K1
265 23K10402 CASE_CONN 1 1 1 309210460K-005
266 4J300191 CAB_JOINTTERMIN 4 4 4 309210460K-006
267 23N20117 TUBE_WIRING 4 4 4 309210460K-007
268 23N20103 TUBE_WIRING 1 1 1 309210460K-008
271 211F8687 BRACKET 1 1 1 309210460J-001
272 4S1B0118 SWITCH_BUTTON 1 1 1 309210460J-002
273 0921E60M CORD 1 1 1 309210460J-003
274 9W310129 CORD 1 1 1 309210460J-004
275 23K10402 CASE_CONN 1 1 1 309210460J-005
276 4J300191 CAB_JOINTTERMIN 4 4 4 309210460J-006
277 23N20117 TUBE_WIRING 4 4 4 309210460J-007
278 23N20103 TUBE_WIRING 1 1 1 309210460J-008
281 211A9124 COVER 1 1 1 3092104308-001
282 4B111494 PCB_MOUNT 1 1 1 3092104308-002
283 221DA051 SEMS_PANHEADSCR 5 5 5 M3L6 3092104308-003
284 23L10074 ACCESSORY_PCB 5 5 5 3092104308-004
285 221HA003 WASHER 5 5 5 3092104308-005
291 211A9123 COVER 1 1 1 3092104309-001
292 4B111494 PCB_MOUNT 1 1 1 3092104309-002
293 221DA051 SEMS_PANHEADSCR 5 5 5 M3L6 3092104309-003
294 23L10074 ACCESSORY_PCB 5 5 5 3092104309-004
295 221HA003 WASHER 5 5 5 3092104309-005
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-10
Fig. K1
ELEVATOR
