SIPLACE Explorer from 3. 11 (R 20 -2) Ausgabe 11/20 20 Edition 15 of 44 Supported Station software versions a nd machine types Station software version Machine types 71 4 DX -series DX1, DX2 SX -series SX1/SX2, SX1/SX2 V…
SIPLACE Explorer from 3.11 (R20-2) Ausgabe 11/2020 Edition
14 of 44
● MS Internet Explorer, one of the following versions:
MS Internet Explorer 9.0
MS Internet Explorer 10.0
MS Internet Explorer 11.0 (in conjunction with Windows 10, Microsoft Edge Browser is not supported)
● Acrobat Reader 10.1
included on the Support Media
4.3 SIPLACE Explorer Client
● Java SE Runtime Environment 8u202
included on the Support Media
● Java jTDS JDBC driver, version 1.3.1
included on the Support Media
● Apache Tomcat 8.5.57 web server,
included on the Support Media
● Visual C++ Runtime 2019
included on the Support Media
● .NET runtime 4.8
included on the Support Media
● MS Excel Viewer, from the Microsoft portal
● MS Internet Explorer, one of the following versions:
MS Internet Explorer 9.0
MS Internet Explorer 10.0
MS Internet Explorer 11.0
MS Internet Explorer 11.0 (in conjunction with Windows 10, Microsoft Edge Browser is not supported)
● Acrobat Reader 10.1
included on the Support Media
4.4 Supported Data Sources
SIPLACE Explorer 3.11 (R20-2) supports data from the following SIPLACE products:
● OIS 18.0, SIS 18.0, SIPLACE Pro 18.0 (R20-2)
● OIS 17.1, SIS 17.1, SIPLACE Pro 17.1 (R20-1)
● OIS 17.0, SIS 17.0, SIPLACE Pro 17.0 (R19-2)
● OIS 16.1, SIS 16.1, SIPLACE Pro 16.1 (R19-1)
● OIS 16.0, SIS 16.0, SIPLACE Pro 16.0 (R18-2)
SIPLACE Explorer from 3.11 (R20-2) Ausgabe 11/2020 Edition
15 of 44
Supported Station software versions and machine types
Station software version
Machine types
714
DX-series DX1, DX2
SX-series SX1/SX2, SX1/SX2 V2, SX1/SX2 V3
X-series S X2 S, X3 S, X4 S, X4 S micron
X4i S, X4i S micron
CA-series CA4, CA4 V2
TX-series TX1, TX2, TX2i, TX2i W, TX2 micron, TX2i micron, TX2i
micron V2
TX V2-series TX1 V2, TX2 V2, TX2i V2
E-series E1 R, R1 L
713
DX-series DX1, DX2
SX-series SX1/SX2, SX1/SX2 V2, SX1/SX2 V3
X-series S X2 S, X3 S, X4 S, X4 S micron
X4i S, X4i S micron
CA-series CA4, CA4 V2
TX-series TX1, TX2, TX2i, TX2i W, TX2 micron, TX2i micron, TX2i
micron V2
TX V2-series TX1 V2, TX2 V2, TX2i V2
E-series E1 R, R1 L
712
DX-series DX1, DX2
SX-series SX1/SX2, SX1/SX2 V2
TX-series TX1, TX2, TX2i, TX2 micron, TX2i micron
TX V2-series TX1 V2, TX2 V2, TX2i V2
X-series S X2 S, X3 S, X4 S, X4 S micron
X4i S, X4i S micron
CA-series CA4 V2
E-series E by SIPLACE
711
DX-series DX1, DX2
SX-series SX1/SX2, SX1/SX2 V2
TX-series TX1, TX2, TX2i, TX2 micron, TX2i micron
TX V2-series TX1 V2, TX2 V2, TX2i V2
X-series S X2 S, X3 S, X4 S, X4 S micron
X4i S, X4i S micron
CA-series CA4 V2
605
D-series D1, D2, D3, D4
SIPLACE Explorer from 3.11 (R20-2) Ausgabe 11/2020 Edition
16 of 44
NOTICE
Discontinued SIPLACE placement machines are not listed in the table above.
The standard SIPLACE Explorer delivery package supports the above listed SIPLACE machines.
SIPLACE Explorer can also be used with other line components (e.g. screen printers and reflow ovens)
and for the evaluation of production performance with the Standard Monitoring Application (SMA) or other
applications.
For detailed information about special components and interfaces, please contact your regional SIPLACE
sales partner.
4.5 Interfaces
SIPLACE Explorer does not provide any interfaces. However, a connection to OIS and SIS does exist, as
SIPLACE Explorer receives all required data from the OIS and SIS via so-called database views. For
further information about OIS and SIS database views, please see the following descriptions:
● SIPLACE OIS / SIS Databases 18.0 Interface Description.
4.6 Possible Placement Data Deviations Between SIPLACE
Explorer and OIS
The number of consumed components, rejects and boards can differ between SIPLACE Explorer and
OIS.
In OIS, each data set has a time stamp (consumed components, rejected components and each board).
If you start an OIS query for the consumption within a specific time period, via SQL Query, OIS will issue
the number of data sets which have a time stamp within this period.
SIPLACE Explorer, on the other hand, assigns the components to the boards on which they are to be
placed. If you start a query for the consumption within a specific time period, SIPLACE Explorer will issue
the number of components which have been placed on the boards which were produced within the
defined period. This difference becomes clearer when we consider production in 2 placement areas.
The following diagram illustrates the difference.
Example: 8 boards were placed on a machine with 2 placement areas. The diagram shows 3 timelines:
● Components for placement area 1
● Components for placement area 2
● Boards
The components X on the timeline for placement area 1 show the possible timestamps for those
components which were placed on board X.
