Melt Flow Index T esters (Plastometers) are commonly used to determine the Melt Flow Rate (MFR) or the Melt Volume Rate (MVR) of plastic pellets, powders and granules . These instruments are designed in compliance with t…
HIGHLIGHTS
• Force-controlled pre-compression/
ejection via drive and automatic
selection of test weights
• Multi-load measurements with up to
eight different weights, ascending,
descending or freely selectable
• Timing accuracy better than 0.001 s
• Temperature control algorithm,
resolution: 0 to 320 °C = 0.01 °C,
320 to 500 °C = 0.1 °C
• High-precision digital displacement
transducer for volume throughput
measurement with automatic
determination of resolution
• Automatic weight selection
Acc. to Standards:
ISO 11443 (Viskosity)
ISO 1133
ASTM D1238
ASTM D3364
mi40 visco
Add-on “visco” for advanced viscosity measurements
10
Melt Flow Index Testers (Plastometers) are commonly used
to determine the Melt Flow Rate (MFR) or the Melt Volume
Rate (MVR) of plastic pellets, powders and granules. These
instruments are designed in compliance with the relevant
standards ISO 1133 and ASTM D1238.
Until now, viscosity measurements according to ISO 11443
required the use of a Capillary Rheometer. Compared to a
plastometer, a Capillary Rheometer is more time consuming
and more demanding in terms of operation.
With the Add-On “visco” for the melt flow index tester mi40,
viscosity measurements can now also be carried out with
a plastometer. In contrast to standard MFR measurements,
significantly higher shear rates can be achieved – a decisive
factor for simulating actual processing conditions.
Thus, viscosity testing with this GÖTTFERT plastometer is
closer to processability control than to a conventional
melt flow index test.
Learn more goettfert.com/mi40-visco
ADD-ON
miCONNECT
Melt density
Moisture Measurement Instrument
VISCOSITY MEASUREMENT
mi40 visco vs. Capillary Rheometer RG20 with
HDPE, MFR (190 °C/2,16 kg) = 9 g/10min
mi40 visco
11
HIGHLIGHTS
• Determination of intrinsic viscosity
without chemical substances
• Easy and fast measuring method
• Characterization of the average
molecular weight of PET/PA/PP
• Stand-alone instrument or with PC
Acc. to Standards:
ISO 12418-2:2012
ISO 1133
ASTM D1238
IV TESTER
Determination of the Intrinsic Viscosity
USED FOR
USED FOR
POLYMER
RECYCLING
