The Melt Flow Indexer mi3 is equipped with a weight magazine that allows the operator to manually select the required test weight. The instrument enables operators in quality control and incoming goods inspection to perf…
HIGHLIGHTS
• Weight magazine with manual weight
selection
• High resolution displacement
measurement (0.006 mm/pulse) with
automatic resolution detection
• Automated pre-compression of the
sample
• Weight-guided test piston
• Individually selectable basic weights
(standard: 1.2 kg)
• Integrated test weights from 2.16 kg
to 21.6 kg (max. 8 weights)
• Individually configurable test weights
• Electronic weight lifting unit
• Stand-alone instrument or PC
operation (miCONNECT)
Acc. to Standards:
ISO 1133
ASTM D1238
ASTM D3364
mi3
Semi-automated Melt Flow Indexer
with permanently integrated test weights for highest demands
6
The Melt Flow Indexer mi3 is equipped with a weight
magazine that allows the operator to manually select the
required test weight.
The instrument enables operators in quality control and
incoming goods inspection to perform single-weight
measurements according to ISO 1133 and ASTM D1238
(Procedure A-B-C).
With its high-resolution displacement measurement and
automatic resolution detection, the mi3 ensures repeatable
and reliable testing of plastics.
In addition to the standardized MFR and MVR measurements
according to ASTM D1238 and ISO 1133, GÖTTFERT Melt Flow
Indexers offer various Add-Ons that provide additional value
in materials testing.
On request, the instrument can also be operated via PC using
our measurement software miCONNECT. Especially for
frequent material changes, a high number of tests, or in-depth
result analysis, the software offers significant advantages.
ADD-ON
miCONNECT
Melt density
Moisture Measurement Instrument
Learn more goettfert.com/mi3
OPTIONEN
• Manual die plug (also heatable for
polymers with high test temperature)
• Automatic die plug
• Automatic melt cutting unit (also for
highly adhesive materials)
• Nitrogen purge unit for hygroscopic
polymers
• Test barrel and piston in corrosion-
resistant or wear-resistant design
• Data backup of all parameter and
measurement values in case of power
failure via UPS
• Optimized piston fixing
• Battery-powered cleaning instrument
• Exhaust unit at the test barrel
• Final acceptance according to ISO 17025
mi3
7
HIGHLIGHTS
• Force-controlled pre-loading/
ejection via drive and automatic
test weight selection
• Multi-load measurements with up
to eight different weights,
ascending, descending or freely
selectable
• Time measurement accuracy better
than 0.001 s
• Temperature control algorithm,
resolution 0 to 320 °C: 0.01 °C,
320 to 500 °C: 0.1 °C
• High precision digital displacement
transducer for volume throughput
measurement with automatic
resolution detection (0.006 mm/
pulse)
• Automatic weight selection
Acc. to Standards:
ISO 1133
ASTM D1238
ASTM D3364
mi40
Semi-automated measurements with highest accuracy
