HIGHLIGHTS • W eight magazine with manual weight selection • High resolution displacement measurement (0.006 mm/pulse) with automatic resolution detection • Automated pre-compression of the sample • W eight-guided test p…

Learn more goettfert.com/mi2

With its automated weight lifting system and the

optional pre-compaction of the material, the mi2

signiﬁcantly reduces operator inﬂuence and ensures high

reproducibility even in demanding applications.

This allows the measurement to start automatically after

the melting time, and the weights can be raised and

conveniently returned to the starting position at the push

of a button.

mi2

ADD-ON

miCONNECT

Melt density

Moisture Measurement Instrument

OPTIONEN

• Die plug and melt cutting unit

• Measurement according to ISO 1133

method A and ASTM D1238 procedure A

possible

• Special capillary (measurements

according to ASTM D1238 procedure C

“half die” or ASTM D3364 possible)

• Nitrogen purge unit

• Die Swell Measurement unit

• Test barrel in corrosion-resistant or

wear-resistant design

• Data backup of all parameter and

measurement values in case of power

failure via UPS

• Pre-compression and extrusion with

higher weight

• Battery-powered cleaning instrument

• Exhaust unit at the test barrel

• Final acceptance according to ISO 17025

HIGHLIGHTS

• Weight magazine with manual weight

selection

• High resolution displacement

measurement (0.006 mm/pulse) with

automatic resolution detection

• Automated pre-compression of the

sample

• Weight-guided test piston

• Individually selectable basic weights

(standard: 1.2 kg)

• Integrated test weights from 2.16 kg

to 21.6 kg (max. 8 weights)

• Individually conﬁgurable test weights

• Electronic weight lifting unit

• Stand-alone instrument or PC

operation (miCONNECT)

Acc. to Standards:

ISO 1133

ASTM D1238

ASTM D3364

mi3

Semi-automated Melt Flow Indexer

with permanently integrated test weights for highest demands

The Melt Flow Indexer mi3 is equipped with a weight

magazine that allows the operator to manually select the

required test weight.

The instrument enables operators in quality control and

incoming goods inspection to perform single-weight

measurements according to ISO 1133 and ASTM D1238

(Procedure A-B-C).

With its high-resolution displacement measurement and

automatic resolution detection, the mi3 ensures repeatable

and reliable testing of plastics.

In addition to the standardized MFR and MVR measurements

according to ASTM D1238 and ISO 1133, GÖTTFERT Melt Flow

Indexers oﬀer various Add-Ons that provide additional value

in materials testing.

On request, the instrument can also be operated via PC using

our measurement software miCONNECT. Especially for

frequent material changes, a high number of tests, or in-depth

result analysis, the software oﬀers signiﬁcant advantages.

ADD-ON

miCONNECT

Melt density

Moisture Measurement Instrument

Learn more goettfert.com/mi3

OPTIONEN

• Manual die plug (also heatable for

polymers with high test temperature)

• Automatic die plug

• Automatic melt cutting unit (also for

highly adhesive materials)

• Nitrogen purge unit for hygroscopic

polymers

• Test barrel and piston in corrosion-

resistant or wear-resistant design
